| Brand | Cisco |
| Model | WS-C4506-S2+96 |
| Bundle Contents | Catalyst 4506 chassis, 1 x 1000 W AC power supply, 1 x Supervisor Engine II-Plus, 2 x WS-X4148-RJ |
| Chassis Slots | 6 (slot 1 supervisor, slots 2 through 6 line cards) |
| Supervisor Engine | WS-X4013+ Supervisor Engine II-Plus |
| Line Cards | 2 x WS-X4148-RJ |
| Line Card Type | 48-port 10/100 RJ-45 |
| Access Ports | 96 x 10/100 RJ-45 |
| Uplink Ports | 2 x Gigabit Ethernet (GBIC) |
| Open Module Slots | 3 |
| Switching Fabric | 64 Gbps (Supervisor Engine II-Plus in Catalyst 4506) |
| Forwarding Rate | 48 Mpps |
| Chassis Backplane | 60 Gbps full duplex |
| Maximum Port Density | 240 |
| MAC Addresses | 32,768 |
| Supervisor CPU | 266 MHz |
| Supervisor DRAM | 256 MB |
| Supervisor Onboard Flash | 32 MB |
| Supervisor Console | RJ-45 |
| Supervisor Management Port | 10/100 RJ-45 |
| Supervisor Redundancy | No |
| PoE | Not supported with the 1000 W AC power supply |
| Power Supply Input | 100 to 240 VAC, 50/60 Hz |
| Power Supply Current | 12 A at 100 VAC, 5 A at 240 VAC |
| Power Supply Output | 1000 W plus 40 W (fan) |
| Power Supply Bays | 2 (second supply optional, 1 + 1 redundancy) |
| Line Card Maximum Rated Power | 65 W each |
| Line Card MTBF | 350,860 hours |
| Fan Assembly | 1 hot-swappable assembly |
| Chassis Dimensions (H x W x D) | 17.38 x 17.31 x 12.50 in (44.13 x 43.97 x 31.70 cm) |
| Rack Units | 10 RU |
| Weight, Chassis and Backplane | 36.5 lb (16.5 kg) |
| Weight, Fan Tray | 4.0 lb (1.8 kg) |
| Weight, 1000 W Power Supply | 11.5 lb (5.22 kg) |
| Operating Temperature | 32 to 104 F (0 to 40 C) |
| Storage Temperature | -40 to 167 F (-40 to 75 C) |
| Operating Humidity | 10% to 90% RH |
| Storage Humidity | 5% to 95% RH |
| Operating Altitude | -500 to 6500 ft (-150 to 2000 m) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
