| Manufacturer | Cisco |
| Product Line | Catalyst 4500-X Series |
| Product Type | Fixed Aggregation Switch |
| Base Ports | 32x 1G/10G (SFP or SFP+) |
| Uplink Module | Optional C4KX-NM-8SFP+ (8-Port), For 40 Total Ports |
| Sibling | WS-C4500X-24X-ES (16+8=24 Ports), WS-C4500X-32SFP+ (32 Ports, IP Base, No Uplink Module) |
| Software License | Enterprise Services (Included) |
| Switching Capacity | 800 Gbps |
| Forwarding Rate (IPv4/IPv6) | Up To 250 Mpps / 125 Mpps |
| L2 Bridging | Up To 250 Mpps |
| Forwarding Entries (IPv4/IPv6) | 256K / 128K |
| Flexible NetFlow Entries | 128K |
| SPAN/RSPAN Sessions | 8 Line-Rate Bidirectional |
| VLANs / SVIs | 4,094 / 4,094 |
| IGMP Groups | 32K |
| Multicast Routes (IPv4/IPv6) | 32K / 32K |
| DHCP Snooping Bindings | 12K |
| ARP Entries | 47K |
| VSS Throughput | Up To 1.6 Tbps, Up To 8 Virtual Switch Links (1GE or 10GE) |
| Management Port | 10/100/1000 RJ-45 Console/Management |
| Storage | External USB and SD Card Support |
| Fans | 5, Field-Replaceable, No Impact From Single Fan Failure |
| MTBF | 199,720 Hours |
| Power Supply Output | 12V @ 62A, 3.3V @ 3A |
| Heat Output (Nominal/Max) | 1,122 BTU/hr (330W) / 1,365 BTU/hr (400W) |
| Dimensions (H x W x D) | 1.75 x 17.25 x 21 in |
| Form Factor | 1U Rack Mountable |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
