| Device Type | Network management device |
| Height (Rack Units) | 1U |
| Built-in Devices | Status LCD |
| Width | 12 in |
| Depth | 8.3 in |
| Height | 1.7 in |
| Weight | 4.54 lbs |
| Localization | United States |
| Form Factor | Rack-mountable |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet Fast Ethernet Gigabit Ethernet |
| Performance | AES throughput: 4.4 Gbps | Firewall throughput: 8 Gbps | 3DES throughput: 2.4 Gbps |
| Capacity | Maximum number of access points: 64 | Concurrent devices: 4096 | Virtual interfaces (VLANs): 4094 | Concurrent GRE tunnels: 2048 | Maximum number of access points (remote): 64 | Concurrent tunneled ports: 2048 | Concurrent IPSec sessions: 2048 | Concurrent SSL fallback sessions: 2048 | Active firewall sessions: 65536 |
| Status Indicators | Status link/activity |
| Features | VPN support auto-negotiation IPv6 support IPv4 support Adaptive Radio Management (ARM) ClientMatch RFProtect |
| Interfaces | 8 x 1000Base-T - RJ-45 | 8 x Ethernet 1000 - SFP (mini-GBIC) | 1 x USB 2.0 - Type A | 1 x management (USB) | 1 x console - RJ-45 |
| MTBF | 390679 hours |
| Compliant Standards | C-Tick CISPR 22 Class B EN 61000-3-2 NOM EN 61000-3-3 EN55022 Class B CB ICES-003 Class B FCC Part 15 B EN 61000-4-4 EN 61000-4-2 EN 61000-4-3 EN 61000-4-6 MIC AS/NZS 3548 EN 61000-4-5 EN 61000-4-11 EN 61000-4-8 UL 60950-1 Second Edition KCC ANATEL cTUVus CSA C22.2 No. 60950-1 Second Edition EN 60950-1 Second Edition IEC 60950-1 Second Edition VCCI Class B KN24 EN 55024: CISPR 24:2010 |
| Power Device | Internal power supply |
| Power Consumption Operational | 55 Watt |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
