| Brand | Cisco |
| Model | CISCO1801/K9 |
| Series | Cisco 1800 Series Integrated Services Routers (Fixed) |
| Cisco Product Description | ADSL over POTS router with 8-port 10/100BASE-T switch, ISDN S/T backup |
| Product Type | Fixed-configuration integrated services router |
| DSL WAN Port | 1 x ADSL over POTS |
| Ethernet WAN Port | 1 x 10/100BASE-T, FE 0 |
| Switch Ports | 8 x 10/100BASE-T fully managed, 802.1Q VLAN support, FE 1 through FE 8 |
| Backup Interface | 1 x ISDN S/T BRI |
| Console Port | 1 x RJ-45, up to 115.2 kbps |
| Auxiliary Port | 1 x RJ-45, up to 115.2 kbps |
| USB Ports | None |
| Flash, Default | 32 MB |
| Flash, Maximum | 128 MB, external CompactFlash |
| DRAM, Default | 128 MB |
| DRAM, Maximum | 384 MB (one SODIMM slot, up to 256 MB module) |
| Boot and NVRAM | 2 MB |
| Inline Power (PoE) | Optional field upgrade, POE-180X, 802.3af on the switch ports |
| IPSec Tunnels | 50 |
| IPSec VPN Performance | 40 Mbps 3DES at 1400 byte packets |
| Recommended Users | 50 |
| AC Input Voltage | 100 to 240 VAC |
| AC Input Frequency | 50 to 60 Hz |
| AC Input Current, Maximum | 1 A |
| Output Power, Maximum | 50 W |
| Power Dissipation | 153 BTU/hr |
| Redundant Power Supply | No |
| DC Power Support | No |
| Dimensions (W x D) | 12.74 x 9.7 in (32.36 x 24.64 cm) |
| Height Without Feet | 1.75 in (4.45 cm) |
| Height With Feet | 1.89 in (4.80 cm) |
| Rack Units | 1 RU, desktop chassis |
| Rack Mount | Optional 19 in kit, ACS-1800-RM-19= |
| Weight, Maximum | 6.1 lb (2.8 kg) |
| Operating Temperature | 32 to 104 F (0 to 40 C) |
| Storage Temperature | -4 to 149 F (-20 to 65 C) |
| Operating Humidity | 10% to 85%, noncondensing |
| Storage Humidity | 5% to 95%, noncondensing |
| Operating Altitude | 10,000 ft (3000 m) at 77 F (25 C) |
| Related Models | CISCO1801-M/K9 (ADSL over POTS Annex M), CISCO1801W-AG-E/K9 (integrated 802.11a/b/g, ETSI) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
