| Brand | Cisco |
| Model | WS-C4500X-F-16SFP+ |
| Product Description | Catalyst 4500-X 16 Port 10GE IP Base, Back-to-Front Cooling, No P/S |
| Series | Cisco Catalyst 4500-X Series |
| Ports | 16 x 1G/10G SFP+/SFP |
| Optional Uplink Module | C4KX-NM-8SFP+ (8 x 1G/10G SFP+/SFP, hot swappable) |
| Feature Set | IP Base (Enterprise Services available as an upgrade) |
| Airflow | Back-to-front |
| System Throughput | Up to 800 Gbps |
| IPv4 Routing in Hardware | Up to 250 Mpps |
| IPv6 Routing in Hardware | Up to 125 Mpps |
| Layer 2 Bridging in Hardware | Up to 250 Mpps |
| VSS | Up to 2 switches, up to 1.6 Tbps |
| MAC Addresses | 55K |
| VLANs | 4094 |
| SVIs | 4094 |
| IPv4 Forwarding Entries | 64K |
| IPv6 Forwarding Entries | 32K |
| IPv4 Multicast Routes | 24K |
| IPv6 Multicast Routes | 12K |
| Power Supply Bays | 2 (power supplies sold separately) |
| Power Supply Options | C4KX-PWR-750AC-F (750 W AC), C4KX-PWR-750DC-F (750 W DC) |
| Power Input | AC 100 to 240 VAC, 50 to 60 Hz; DC -72 to -40 VDC |
| System Power | 330 W nominal, 400 W maximum |
| Fans | 5, field-replaceable |
| MTBF | 209,330 hours |
| Dimensions (H x W x D) | 1.75 x 17.25 x 21 in (4.4 x 43.8 x 53.3 cm) |
| Weight | 19 lb (8.62 kg) without power supplies |
| Operating Temperature | 0 to 40 C |
| Storage Temperature | -40 to 70 C |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
