| Manufacturer | Cisco Systems |
| Product Line | Catalyst 3560-X Series |
| Part Number | WS-C3560X-48PF-S |
| Product Type | Layer 3 Standalone Access Switch |
| Access Ports | 48x 10/100/1000BASE-T RJ-45 (PoE+) |
| PoE Standard | IEEE 802.3af; IEEE 802.3at (PoE+); 30W max per port |
| PoE Budget | 800W |
| Uplink/Expansion | 1x network module slot (C3KX-NM-1G; C3KX-NM-10G; C3KX-NM-10GT) |
| Switching Capacity | 160 Gbps |
| Forwarding Rate | 101.2 Mpps |
| DRAM | 256 MB |
| Flash | 128 MB |
| License | IP Base (IP Services upgrade available via license) |
| Layer 2 | VLAN; 802.1Q; STP; RSTP; MSTP; LACP; IGMP snooping; MACsec |
| Layer 3 (IP Base) | Static routing; RIP; OSPF routed access; EIGRP stub |
| Security | 802.1X; MACsec; ACLs; DHCP snooping; dynamic ARP inspection; IP source guard |
| Management | CLI; SNMP v1/v2c/v3; RMON; 1x RJ-45 console; 1x USB Type-B; 1x RJ-45 OOB management |
| Power Supply | 1100W AC (included); 2nd slot for optional redundancy |
| Form Factor | 1U rack-mountable; standalone |
| Dimensions | 1.75 x 17.50 x 18.0 in |
| Weight | 15.65 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
