| Brand | Cisco |
| Model | WS-C2960XR-24PS-I |
| Series | Cisco Catalyst 2960-XR Series |
| Cisco Product Description | Catalyst 2960-XR 24 GigE PoE 370W, 4 x 1G SFP, IP Lite |
| Ports | 24 x 10/100/1000 |
| Uplink Ports | 4 x 1 Gigabit SFP |
| Feature Set | IP Lite |
| PoE Capacity | 12 ports up to 30 W (IEEE 802.3at); 24 ports up to 15.4 W (IEEE 802.3af) |
| PoE Budget | 370 W |
| Perpetual PoE | Supported |
| Default Power Supply | PWR-C2-640WAC (640 W AC) |
| Redundant Power | Dual redundant power supplies supported |
| Forwarding Bandwidth | 108 Gbps |
| Switching Bandwidth | 216 Gbps |
| Forwarding Rate | 71.4 Mpps |
| Maximum Active VLANs | 1023 |
| VLAN IDs | 4096 |
| Unicast MAC Addresses | 16,000 (default profile) |
| IPv4 Unicast Routes | 4,000 direct and 1,250 indirect (default profile) |
| IPv4 QoS ACEs | 500 (default profile) |
| IPv4 Security ACEs | 1,000 (default profile) |
| IPv6 Security ACEs | 500 (default profile) |
| IPv4 Policy-Based Routing ACEs | 500 (default profile) |
| Flash | 128 MB |
| CPU | APM86392, 600 MHz dual core |
| FlexStack-Plus | 80 Gbps, up to 8 switches |
| FlexStack-Extended | 40 Gbps, up to 8 switches |
| Stack Module | FlexStack-Plus module, hot-swappable |
| Stacking Cables | CAB-STK-E-0.5M, CAB-STK-E-1M, CAB-STK-E-3M |
| Console Ports | USB (Type B), Ethernet (RJ-45) |
| Console Cables | CAB-CONSOLE-RJ45 (6 ft); CAB-CONSOLE-USB (6 ft) |
| Management Port | 10/100 Mbps Ethernet (RJ-45) |
| USB Port | USB Type A for external flash storage |
| Dimensions (H x D x W) | 1.75 x 16.0 x 17.5 in (4.45 x 40.8 x 44.5 cm) |
| Additional Depth With Power Supplies | Up to 3.1 in (7.9 cm) |
| Weight | 13.7 lb (6.2 kg) |
| Operating Temperature | -5 to 45 C (23 to 113 F) up to 5,000 ft (1,500 m) |
| Operating Temperature at Altitude | -5 to 40 C (23 to 104 F) up to 10,000 ft (3,000 m) |
| Operating Relative Humidity | 10% to 95%, noncondensing |
| Operating Altitude | Up to 10,000 ft (3,000 m) |
| Acoustic Noise | 40 dB typical, 43 dB maximum sound pressure; 5.2 B typical, 5.5 B maximum sound power |
| MTBF | 321,290 hours |
| Input Current | 6 A to 3 A |
| Power Rating | 0.46 kVA |
| Power Consumption | 36.5 W at 0% traffic, 43.2 W at 10%, 43.4 W at 100%, 43.2 W weighted average |
| Safety | UL 60950-1 Second Edition; EN 60950-1 Second Edition; IEC 60950-1 Second Edition |
| EMC | 47CFR Part 15 Class A; CISPR22 Class A; EN55022 Class A; EN55024; CISPR24; EN300386 |
| Related Models | WS-C2960XR-24PD-I (24 ports, 2 x SFP+ uplinks, 370 W PoE); WS-C2960XR-24TS-I (24 ports, 4 x SFP uplinks, no PoE) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
