| Device Type | Switch - 8 ports - managed |
| Enclosure Type | Desktop rack-mountable wall-mountable 1U |
| Subtype | Fast Ethernet |
| Ports | 8 x 10/100 2 x shared Gigabit SFP |
| Performance | Forwarding performance: 10 Gbps | Forwarding performance (64-byte packet size): 3.8 Mpps |
| Capacity | Virtual interfaces (VLANs): 255 |
| Jumbo Frame Support | 9018 bytes |
| Routing Protocol | RIP-1 RIP-2 |
| Remote Management Protocol | SNMP 1 SNMP 2 RMON 1 RMON 2 RMON 3 RMON 9 Telnet SNMP 3 SNMP 2c HTTP CLI |
| Authentication Method | Kerberos Secure Shell (SSH) RADIUS TACACS |
| Features | DHCP support auto-negotiation BOOTP support ARP support VLAN support auto-uplink (auto MDI/MDI-X) IGMP snooping Syslog support DiffServ support Broadcast Storm Control IPv6 support Multicast Storm Control Unicast Storm Control Spanning Tree Protocol (STP) support DHCP snooping Dynamic Trunking Protocol (DTP) support Port Aggregation Protocol (PAgP) support Trivial File Transfer Protocol (TFTP) support Access Control List (ACL) support Quality of Service (QoS) Dynamic ARP Inspection (DAI) STP Root Guard Uni-Directional Link Detection (UDLD) fanless DHCP relay Link Aggregation Control Protocol (LACP) Remote Switch Port Analyzer (RSPAN) |
| Compliant Standards | IEEE 802.3 IEEE 802.3u IEEE 802.3z IEEE 802.1D IEEE 802.1Q IEEE 802.3ab IEEE 802.1p IEEE 802.3x IEEE 802.3ad (LACP) IEEE 802.1w IEEE 802.1x IEEE 802.1s IEEE 802.1ae IEEE 802.1ab (LLDP) |
| RAM | 128 MB |
| Flash Memory | 64 MB |
| Status Indicators | Port status system link/activity |
| Interfaces | 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45 | 8 x 10Base-T/100Base-TX - RJ-45 | 1 x console - mini-USB Type B management | 1 x RS-232 - RJ-45 management | 2 x SFP (mini-GBIC) | 1 x USB Type A |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| MTBF | 516980 hours |
| Compliant Standards | GOST CISPR 24 EN55022 VCCI Class A ITE EN55024 CISPR 22 CCC RoHS UL 60950-1 IEC 60950-1 EN 60950-1 CSA C22.2 No. 60950-1 GB 4943 |
| Software Included | Cisco IOS LAN Base |
| Width | 10.6 in |
| Depth | 8.4 in |
| Height | 1.7 in |
| Weight | 2.38 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
