| Device Type | Expansion module |
|---|---|
| Form Factor | Plug-in module |
| Connectivity Technology | Wired |
| Data Link Protocol | HDLC Frame Relay PPP |
| Data Transfer Rate | 44.736 Mbps |
| Network / Transport Protocol | IPSec |
| Line Rate | T-3/E-3 |
| Line Coding Format | HDB3 B3ZS |
| Status Indicators | Status alarm |
| Features | NAT support Intrusion Detection System (IDS) Quality of Service (QoS) NetFlow |
| Compliant Standards | ANSI T1.107 G.703 ITU-T G.823 |
| Interfaces | 1 x T3/E3 - BNC - x 2 |
| Compliant Standards | TUV GS EN 60950 EN 61000-3-2 IEC950 EN 61000-3-3 EN55024 EN55022 Class A AS/NZS 3260 EN 61000-4-4 EN 61000-4-2 EN 61000-4-3 EN 61000-4-6 AS/NZ 3548 Class A ICES-003 Class A EN 61000-4-5 UL 1950 Third Edition EN 61000-6-2 EN 61000-4-11 FCC CFR47 Part 15 CSA C22.2 No. 950 VCCI V-3 EN 50082-1:1997 EN41003 EN 300386 |
| Width | 7.1 in |
| Depth | 7.2 in |
| Height | 1.5 in |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
