| Device Type | Switch - 24 ports - L3 - managed |
| Enclosure Type | Rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 (PoE ) 2 x Gigabit SFP |
| Power Over Ethernet (PoE) | PoE |
| Performance | Non-blocking switching capacity: 26 Gbps | Switching capacity: 52 Gbps | Forwarding performance: 38.69 Mpps |
| Capacity | VLANs supported: 255 | ACL rules: 100 | LAG groups: 6 |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | Yes |
| Routing Protocol | Static IP routing policy-based routing (PBR) |
| Remote Management Protocol | SNMP 1 SNMP 2 Telnet SNMP 3 HTTP SSH-2 CLI |
| Features | Flow control BOOTP support VLAN support IGMP snooping Syslog support port mirroring DiffServ support Broadcast Storm Control IPv6 support Multicast Storm Control Unicast Storm Control Spanning Tree Protocol (STP) support Rapid Spanning Tree Protocol (RSTP) support Multiple Spanning Tree Protocol (MSTP) support DHCP snooping Access Control List (ACL) support Quality of Service (QoS) RADIUS support Uni-Directional Link Detection (UDLD) LLDP support Link Aggregation Control Protocol (LACP) Dynamic VLAN Support (GVRP) Class of Service (CoS) Generic Attribute Registration Protocol (GARP) |
| Compliant Standards | IEEE 802.3 IEEE 802.3u IEEE 802.1D IEEE 802.1Q IEEE 802.3ab IEEE 802.1p IEEE 802.3af IEEE 802.3x IEEE 802.3ad (LACP) IEEE 802.1w IEEE 802.1x IEEE 802.1s IEEE 802.3ak IEEE 802.1ab (LLDP) IEEE 802.3at |
| Status Indicators | Port transmission speed PoE link/activity |
| Interfaces | 24 x 1000Base-T RJ-45 PoE - 34.2 W | 2 x 1000Base-X SFP |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50 - 60 Hz) |
| Power Consumption Operational | 250 Watt |
| Compliant Standards | IC FCC ETSI 300 019 |
| Width | 19.1 in |
| Depth | 11.2 in |
| Height | 1.7 in |
| Weight | 8.16 lbs |
| Min Operating Temperature | 23 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
