| Manufacturer | Cisco |
| Model | N9K-C93180LC-EX |
| Series | Nexus 9300-EX |
| Switch Type | Layer 3 Data Center Switch |
| ASIC | Cisco Cloud Scale |
| Downlink Ports | 24 x 40/50GE QSFP+ |
| Uplink Ports | 6 x 40/100GE QSFP28 |
| Flexible Configurations | Up to 32x 40/50GE, or up to 18x 100GE, or up to 72x 10GE (breakout) |
| Switching Capacity | 3.6 Tbps |
| Forwarding Rate | 2.6 Bpps |
| MAC Address Table | 256,000 entries |
| IPv4 Host Entries | 896,000 |
| LPM Routes | 896,000 |
| Multicast Routes | 32,000 |
| VLANs | 4,096 |
| VRF Instances | 1,000 (max 16,000) |
| System Buffer | 40 MB |
| Operating Modes | NX-OS, ACI |
| Routing | OSPF, BGP, EIGRP, RIP, IS-IS, HSRP, PIM-SM, MSDP, ECMP (64-way), MPLS |
| Data Center Features | VXLAN EVPN, vPC, ISSU, NPV Gateway |
| Buffer Management | Approximate Fair Dropping (AFD), Dynamic Packet Prioritization |
| CPU | 4-core |
| RAM | 24 GB |
| SSD | 64 GB |
| Management | 1 x RJ-45 mgmt, 1 x SFP+ mgmt, 1 x USB, 1 x RS-232 console |
| Power Supply Options | 500W AC, 930W DC, 1200W HVAC/HVDC (N+1 redundant, hot-swappable) |
| Fans | 4 (hot-swappable) |
| Airflow | Front-to-back or back-to-front (different SKUs) |
| Form Factor | Rack-mountable (1U) |
| Dimensions (H x W x D) | 1.73 x 17.3 x 22.5 in |
| Weight | 17.2 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
