| Manufacturer | Cisco |
| Part Number | N3K-C3172TQ-10GT |
| Product Line | Cisco Nexus 3100 Series |
| Product Type | Layer 2/3 10GBase-T Top-of-Rack Data Center Switch |
| 10GBase-T Ports | 48x autosensing 100Mbps/1G/10GBASE-T RJ-45 |
| QSFP+ Ports | 6x QSFP+ (40GbE per port; or 4x10GbE via breakout cable) |
| Max 10GbE Ports | 72 (48x RJ-45 + 24x via QSFP+ breakout) |
| Management Ports | 1x 10/100/1000 RJ-45 OOB; 1x RS-232 console; 1x USB flash |
| Switching Capacity | 1.4 Tbps |
| Forwarding Rate | Up to 1 Bpps |
| Packet Buffer | 12 MB shared |
| Jumbo Frames | Up to 9,216 bytes |
| System Memory | 4 GB |
| Boot Flash | 16 GB |
| VLANs | Up to 4,000 |
| Routing Table | 16,000 prefixes; 16,000 host entries; 8,000 multicast routes |
| EtherChannels | 64 (with vPC); up to 32 ports per EtherChannel |
| Operating System | Cisco NX-OS (Nexus 9000 mode supported with license) |
| Layer 2/3 Features | vPC; 64-way ECMP; OSPF; BGP; PIM; VRF; VXLAN; FabricPath; IGMP; BFD; IPv4/IPv6 |
| Security | ACLs; DHCP snooping; Dynamic ARP Inspection; IP source guard; CoPP; 802.1X; port security |
| Airflow | Back-to-front (port-side intake); -10GT suffix |
| Power Supplies | 2x NXA-PAC-500W hot-swap AC (included); dual redundant |
| Fans | 4x redundant hot-swap (3+1) |
| Form Factor | 1RU rack-mountable |
| Dimensions (H x W x D) | 1.72 x 17.3 x 19.7 in (4.4 x 43.9 x 50.5 cm) |
| Weight | 22 lbs (10 kg) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
