| Manufacturer | Cisco |
| Product Line | Industrial Ethernet 5000 Series |
| Product Type | Ruggedized Industrial Switch |
| SFP Ports | 16x (1G Only, No 10G) |
| PoE Ports | 12x GE PoE+ |
| Total Ports | 28 |
| Sibling | IE-5000-12S12P-10G, 4 Uplinks at 1G or 10G, SFP+ Heater for -40°C Optics |
| Switching Capacity | 20 Gbps Nonblocking (Series-Wide) |
| Forwarding Rate | Line Rate For All Ports and All Packet Sizes |
| Memory | 1GB DRAM, 128MB Onboard Flash, 1GB Removable SD Flash Card |
| Default Software | LAN Base (IOS) |
| Redundancy Protocols | REP, PRP, MRP Ring, HSR, EtherChannel, Flex Links |
| Industrial Protocols | EtherNet/IP (CIP), PROFINET, Modbus TCP |
| Management Ports | 1x RJ-45 Console, 1x USB Mini-Type B Console |
| Alarm I/O | 2x Alarm Input (Dry Contact), 1x Alarm Output Relay |
| Cooling | Fanless, Convection-Cooled, No Moving Parts |
| Operating Temperature | -40 to 75°C (-40 to 70°C Vented, -40 to 60°C Sealed Enclosure) |
| Storage Temperature | -40 to 85°C |
| Humidity | 5 to 95% Non-Condensing |
| Altitude | Up To 15,000 ft |
| Ingress Protection | IP30 (EN60529) |
| MTBF | 536,220 Hours |
| Mounting | DIN Rail Compliant |
| Dimensions (H x W x D) | 6.12 x 6.12 x 5.09 in |
| Weight | 6.35 lb (2.88 kg) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
