| Manufacturer | Cisco |
| Product Line | Cisco Catalyst |
| Series | Catalyst 9500 |
| Product Type | Stackable Managed Switch — Core / Aggregation |
| Ports | 40 x 1G/10G SFP+ (no PoE) |
| Uplink Module Slot | 1 x modular — C9500-NM-2Q (2x 40G QSFP+), C9500-NM-8X (8x 1/10G SFP+); no module included |
| Switching Capacity | 960 Gbps (nonblocking) |
| Forwarding Rate | 720 Mpps |
| ASIC | Cisco UADP 2.0 XL |
| CPU | 4-core Intel x86 2.4 GHz |
| DRAM | 16 GB DDR4 |
| Internal Storage | 16 GB (up to 120 GB USB 3.0 or 960 GB SATA SSD for app hosting) |
| MAC Address Table | 64,000 entries |
| VLANs | 4,000 |
| SVIs | 4,000 |
| IPv4 Routes | 64,000 indirect / 32,000 host |
| IPv6 Routes | 32,000 indirect / 16,000 host |
| Multicast Scale | 48,000 |
| ACL Scale | 18,000 entries (security and QoS) |
| FNF Entries | 512,000 flows |
| StackWise Virtual | Yes — 2-switch virtual chassis, NSF/SSO, ISSU |
| Layer 3 | OSPFv2/v3, EIGRP, BGP, VRF-Lite, MPLS, VXLAN EVPN, PIM-SM/SSM |
| Security | MACsec 256-bit, TrustSec SGT, 802.1X, CoPP, Trustworthy Systems |
| License | Network Advantage |
| Operating System | Cisco IOS XE |
| Power Supply | 2 slots — PWR-C4-950WAC-R or PWR-C4-950WDC-R; 1+1 redundancy |
| Airflow | Front-to-back (FAN-T4-R, qty 5) |
| Input Voltage | 90 to 264 VAC |
| MTBF | 277,310 hours |
| Form Factor | 1U rack-mountable |
| Dimensions | 1.73 x 17.50 x 21.52 in. |
| Weight | 25.75 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
