| Brand | Cisco |
| Model | C1-C4500X-32SFP+ |
| Series | Cisco Catalyst 4500-X Series |
| Ports | 32 x 1G/10G SFP+/SFP |
| Optional Uplink Module | C4KX-NM-8SFP+ (8 x 1G/10G SFP+/SFP) |
| System Throughput | Up to 800 Gbps |
| IPv4 Routing in Hardware | Up to 250 Mpps |
| IPv6 Routing in Hardware | Up to 125 Mpps |
| Layer 2 Bridging in Hardware | Up to 250 Mpps |
| VSS | Up to 2 switches, up to 1.6 Tbps |
| Virtual Switch Link | 1G or 10G, up to 8 VSLs |
| CPU | Dual core 1.5 GHz |
| Memory | 4 GB DDR-II SRAM |
| NVRAM | 2 GB |
| Port Buffers | 32 MB shared |
| MAC Addresses | 55K |
| VLANs | 4094 |
| SVIs | 4094 |
| IPv4 Forwarding Entries | 256K |
| IPv6 Forwarding Entries | 128K |
| IPv4 Multicast Routes | 32K |
| IPv6 Multicast Routes | 32K |
| Console Port | RJ-45 |
| Management Port | 10/100/1000 Ethernet |
| USB Port | 1 x Type A |
| SD Card Slot | Yes (2 GB optional card) |
| Power Supply Bays | 2 (AC or DC, mixed allowed) |
| Power Supply Options | C4KX-PWR-750AC-R/-F (750 W AC), C4KX-PWR-750DC-R/-F (750 W DC) |
| Power Input | AC 100 to 240 VAC, 50 to 60 Hz; DC -72 to -40 VDC |
| Fans | 5, field-replaceable |
| Dimensions (H x W x D) | 1.75 x 17.25 x 21 in (4.4 x 43.8 x 53.3 cm) |
| Weight | 19 lb (8.62 kg) without power supplies |
| Operating Temperature | 10 to 40 C |
| Storage Temperature | -40 to 70 C |
| Operating Humidity | 8% to 80% RH |
| Storage Humidity | 5% to 95% RH |
| Operating Altitude | -50 to 6,500 ft (-16 to 1,981 m) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
