| Device Type | Switch - 48 ports - managed |
| Enclosure Type | Back to front airflow rack-mountable 1U |
| Subtype | 25 Gigabit Ethernet |
| Ports | 48 x 10/25 Gigabit SFP / SFP28 6 x 40/100 Gigabit QSFP28 |
| Performance | Throughput: 1.8 Tbps | Forwarding capacity: 2.1 Bpps |
| VLAN IDs | 4096 |
| Link aggregation groups | 128 |
| Maximum member ports per LAG | 64 |
| IPv4 routes (Unicast prefixes) | 128000 |
| IPv4 routes (Unicast host routes) | 104000 |
| IPv4 routes (Multicast) | 52000 |
| IPv6 routes (Multicast) | 28000 |
| IPv6 routes (Unicast prefixes) | 98000 |
| IPv6 routes (Unicast host routes) | 52000 |
| ARP entries | 32000 |
| GRE tunnels | 1024 |
| MPLS labels | 16000 |
| MSTP instances | 64 |
| VSTP instances | 253 |
| QoS hardware queues per port | 10 |
| MAC Address Table Size | 136K entries |
| Jumbo Frame Support | 9216 bytes |
| Routing Protocol | OSPF IS-IS RIP-1 RIP-2 BGP IGMPv2 IGMP VRRP OSPFv2 PIM-SM static IP routing PIM-DM GRE OSPFv3 PIM-SSM MLDv2 MLD |
| Remote Management Protocol | SNMP 1 SNMP 2 Telnet SNMP 3 SSH CLI |
| Authentication Method | Secure Shell (SSH) RADIUS TACACS Secure Shell v.2 (SSH2) |
| Processor | 1 x Intel: 2.3 GHz |
| RAM | 16 GB SDRAM |
| Built-in Devices | 32 GB SSD |
| Interfaces | 1 x management (Gigabit LAN) RJ-45 management | 1 x console RJ-45 management | 1 x USB 2.0 Type A | 48 x 10Gbit LAN SFP | 6 x 100Gbit LAN QSFP28 |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 2 (installed) / 2 (max) |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1 1 |
| Power Provided | 650 Watt |
| Voltage Required | AC 120/230 V |
| Power Consumption Operational | 382 Watt |
| TAA Compliant | Yes |
| Width | 17.4 in |
| Depth | 20.3 in |
| Height | 1.7 in |
| Weight | 21.16 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
