| Device Type | Switch - 48 ports - L3 - managed |
| Enclosure Type | Front to back airflow rack-mountable 1U |
| Subtype | 10 Gigabit Ethernet |
| Ports | 48 x 1 Gigabit / 10 Gigabit SFP 4 x 40 Gigabit / 100 Gigabit QSFP28 |
| Performance | Switching capacity: 1.76 Tbps | Switching capacity: 1.32 Bpps |
| MAC address entries | 288000 |
| VLAN IDs | 4093 |
| LAG groups | 104 |
| Maximum member ports per LAG | 32 |
| Firewall ingress filters | 6142 |
| Firewall egress filters | 1022 |
| IPv4 routes (Unicast) | 128000 |
| IPv4 routes (Multicast) | 104000 |
| IPv6 routes (Multicast) | 52000 |
| IPv6 routes (Unicast) | 84000 |
| ARP entries | 48000 |
| Jumbo frame size | 9216 |
| MSTP instances | 64 |
| VSTP instances | 253 |
| QoS hardware queues per port | 12 |
| MAC Address Table Size | 288K entries |
| Jumbo Frame Support | 9216 bytes |
| Routing Protocol | OSPF RIP IS-IS BGP IGMPv2 IGMP VRRP static IP routing IGMPv3 |
| Remote Management Protocol | SNMP 1 SNMP 2 Telnet SNMP 3 TFTP CLI |
| Authentication Method | Secure Shell (SSH) RADIUS TACACS Secure Shell v.2 (SSH2) |
| Interfaces | 48 x 1/10Gbit LAN SFP | 4 x 100Gbit/40Gbit LAN QSFP28/QSFP | 1 x USB 2.0 | 1 x serial (RS-232) | 2 x management |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 2 (installed) / 2 (max) |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1 1 |
| Voltage Required | AC 120/230 V |
| Power Consumption Operational | 195 Watt |
| Width | 17.4 in |
| Depth | 20.5 in |
| Height | 1.7 in |
| Weight | 22.99 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
