| Device Type | Switch - 12 ports - L3 - managed |
| Enclosure Type | Rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 12 x 10/100/1000 2 x Gigabit SFP / 10 Gigabit SFP |
| Performance | Switching capacity: 64 Gbps | Throughput: 47 Mpps |
| LAG groups | 128 |
| Maximum member ports per LAG | 8 |
| Multiple Spanning Tree Protocol instances | 64 |
| ARP entries | 1024 |
| IPv4 routes (Unicast) | 512 |
| IPv4 hosts | 4096 |
| IPv4 routes (Multicast) | 2048 |
| Maximum of neighboring networks | 750 |
| IPv6 routes (Unicast) | 128 |
| IPv6 hosts | 2048 |
| IPv6 routes (Multicast) | 1024 |
| QoS hardware queues per port | 8 |
| IGMP snooping entries | 1000 |
| Virtual interfaces (VLANs) | 2048 |
| MAC Address Table Size | 16000 entries |
| Jumbo Frame Support | 9216 bytes |
| Routing Protocol | RIP-1 RIP-2 OSPFv3 static IPv4 routing static IPv6 routing RIPng CIDR |
| Remote Management Protocol | SNMP 1 RMON 1 RMON 2 SNMP RMON 3 RMON 9 Telnet SNMP 3 SNMP 2c HTTP HTTPS TFTP SSH CLI |
| Encryption Algorithm | MD5 TLS PEAP TTLS |
| Authentication Method | RADIUS TACACS Secure Shell v.2 (SSH2) Extensible Authentication Protocol (EAP) |
| Processor | 1 x ARM: 1.25 GHz |
| RAM | 2 GB |
| Flash Memory | 2 GB |
| Interfaces | 12 x 1000Base-T RJ-45 | 2 x 10Gbit LAN SFP | 1 x serial management | 1 x 100Base-TX RJ-45 management |
| Power Device | Internal power supply |
| Power Provided | 40 Watt |
| Power Consumption Operational | 20 Watt |
| Width | 11 in |
| Depth | 9.4 in |
| Height | 1.7 in |
| Weight | 5.47 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
