| Manufacturer | HPE Aruba Networking |
| Series | CX 6200F |
| Product Type | Layer 2/3 Access Switch |
| Port Configuration | 24x 1GbE Ports + 4x SFP+ Uplinks |
| PoE | None (Non-PoE Model; PoE variant is JL725A) |
| CPU | Quad-Core ARM Cortex-A72 @ 1.8 GHz |
| Memory | 8 GB DDR4 RAM / 16 GB eMMC Storage |
| Switching Capacity | 128 Gbps |
| Forwarding Rate | Up to 95.2 Mpps |
| Packet Buffer | 8 MB |
| MAC Address Table | 16,000 Entries |
| VLANs | 2,000 Simultaneous (4,094 VLAN IDs) |
| Jumbo Frame Size | 9,198 Bytes |
| Spanning Tree | IEEE 802.1D, 802.1w (RSTP), 802.1s (MSTP) |
| IPv4/IPv6 Host Table | 8,192 / 8,192 |
| IPv4/IPv6 Routes | 2,048 / 1,024 |
| Routing Protocols | RIPv2, OSPFv2/v3 (Single-Area), Static, ECMP |
| Authentication | 802.1X Supplicant, RADIUS/TACACS+, MAC-Based, Captive Portal |
| ACL Scale | 5,120/1,280/5,120 Ingress (IPv4/IPv6/MAC), 2,048/512/2,048 Egress |
| Other Security | Port Security, Dynamic ARP Protection, FIPS 140-2 Validated Cryptography |
| Management | CLI, REST API, HPE Aruba Central, Aruba Network Analytics Engine (NAE), Aruba CX Mobile App (ZTP) |
| QoS | Strict Priority + DWRR Queuing, IEEE 802.1p, Rate Limiting, Egress Queue Shaping |
| Multicast | IGMP Snooping, MLD, PIM (Sparse/SSM/Dense), 1,024 IGMP/MLD Groups |
| Stacking | HPE Aruba Networking VSF, Up to 8 Members, Long-Range Transceivers to 10km |
| Power Supply | Fixed Internal, 200W |
| Power Consumption | Idle 49W / 100% Traffic 59W (at 230V) |
| Operating Temperature | 32-113F (0-45C) |
| Humidity | 15-95% Non-Condensing |
| Dimensions (H x W x D) | 1.73 x 17.4 x 12.9 in |
| Weight | 9.61 lb |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
