CISCO WS-X4748-12X48U E CATALYST 4500E 48-PORT UPOE SWITCH

Roll over image to zoom in Click on image to zoom

CISCO WS-X4748-12X48U+E

The Supervisor Engine 8-E is the first Cisco Catalyst supervisor engine that enables wired plus wireless services on a single Cisco IOS XE software-based platform. With this functionality, Cisco has pioneered a host of rich capabilities such as high availability based on stateful switchover (SSO), granular QoS, security, and Flexible Netflow (FNF) across wired and wireless networks in a seamless fashion.

Customer Support

We commit to providing excellence in customer service. We are available 24/7, highly responsive, transparent and offer product, transaction and logistics support.
Our philosophy is to be a part of the solution for our clients, so please contact us with any questions or concerns. Check our feedback rating to see what others thought about their experience with us. We look forward to offering you a Five Star member service.

For more information please visit our support page.

Device Type	Control processor
Bundled with	2 x Cisco mGig Line Cards (WS-X4748-12X48U E)
Processors Installed	1 x 2 GHz
RAM	4 GB SDRAM
Flash Memory	2 GB
Form Factor	Plug-in module
Connectivity Technology	Wired
Data Link Protocol	Ethernet Fast Ethernet Gigabit Ethernet 10 Gigabit Ethernet
Switching Protocol	Ethernet
Network / Transport Protocol	ARP DHCP IPv4 IPv6
Routing Protocol	MLD
Remote Management Protocol	RMON 1 RMON 2
Performance	Switching capacity: 928 Gbps \| Per-slot switching capacity: 48 Gbps \| IPv6 routing: 125 Mpps \| IPv4 routing: 250 Mpps
Capacity	QoS hardware entries: 128000 \| Security services entries: 128000 \| Virtual interfaces (VLANs): 4094 \| ARP entries: 47000 \| MAC addresses: 55000 \| IPv6 routes: 128000 \| IPv4 routes: 256000 \| Spanning Tree Protocol instances: 10000 \| Switched virtual interfaces (SVIs): 4094 \| DHCP snooping entries: 12000 \| Spanning Tree Protocol instances: 10000 \| Switched virtual interfaces (SVIs): 4094 \| SPAN bidirectional sessions: 8
Features	VLAN support IPv6 support Non-Stop Forwarding (NSF) Stateful switchover (SSO) Spanning Tree Protocol (STP) support Rapid Spanning Tree Protocol (RSTP) support Multiple Spanning Tree Protocol (MSTP) support Access Control List (ACL) support Quality of Service (QoS) MLD snooping Cisco EnergyWise technology Energy Efficient Ethernet Virtual Routing and Forwarding (VRF) Class of Service (CoS) Flexible NetFlow (FNF)
Compliant Standards	IEEE 802.3 IEEE 802.1D IEEE 802.1Q IEEE 802.1p IEEE 802.3ad (LACP) IEEE 802.1w IEEE 802.1x IEEE 802.3ae IEEE 802.1s IEEE 802.3az
Supported Flash Memory Cards	SD Memory Card
Interfaces	1 x management - RJ-45 \| 1 x 1000Base-T (management) - RJ-45 \| 1 x USB - Type A \| 8 x 10Gb Ethernet - SFP
Compliant Standards	Plug and Play CISPR 22 Class A CISPR 24 EN55024 EN55022 Class A AS/NZS 60950-1 ICES-003 Class A IEC 60950-1 EN 60950-1 UL 60950-1 Second Edition RoHS VCCI Class A EN61000-3-2 EN61000-3-3 FCC CFR47 Part 15 A CAN/CSA C22.2 No. 60950-1 Second Edition AS/NZS CISPR22 Class A EN 300386

We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.

CISCO WS-X4748-12X48U+E CATALYST 4500E 48-PORT UPOE SWITCH

Overview

CISCO WS-X4748-12X48U+E

CISCO WS-X4748-12X48U+E CATALYST 4500E 48-PORT UPOE SWITCH
