| Model | Cisco UCS-C220-M5 (LFF base chassis) |
| Form Factor | 1U rack server |
| Base Configuration | Chassis only; CPU, memory, drives, power supply, SD cards, PCIe cards, and rail kit are sold separately |
| Drive Bays | Up to 4 x 3.5-inch SAS/SATA HDD/SSD bays, plus up to 2 NVMe PCIe drives |
| CPU Support | One or two 2nd Generation Intel Xeon Scalable processors |
| Memory | 24 DIMM slots (RDIMM/LRDIMM/TSV), 6 channels per CPU, up to 2 DIMMs per channel |
| PCIe Expansion | 1x full-height x16 PCIe 3.0 slot, 1x half-height x16 PCIe 3.0 slot, dedicated internal RAID controller slot |
| Power Supply Options | 770W AC, 1050W AC, 1050W DC, 1050ELV AC, 1600W AC (dual redundant supported) |
| Management | Cisco Integrated Management Controller (IMC), Cisco Intersight ready |
| Dimensions | 1.7 x 16.9 x 29.5 in. (43.2 x 429.0 x 740.3 mm), server only; 31.0 in. (787.4 mm) depth with slide rail |
| Weight | 29.0 to 37.5 lb (13.2 to 17.0 kg) as configured with components; this bare-chassis PID ships lighter with no CPU, memory, or drives installed |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
