| Device Type | Switch - 32 ports - managed |
| Enclosure Type | Rack-mountable 1U |
| Subtype | 10 Gigabit Ethernet |
| Ports | 12 x 10 Gigabit / FCoE SFP |
| Performance | Throughput: 960 Gbps |
| MAC Address Table Size | 32000 entries |
| Jumbo Frame Support | 9216 bytes |
| Remote Management Protocol | RMON |
| Features | Layer 2 switching, IGMP snooping, Data Center Bridging Exchange (DCBX) support, Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST ) |
| Compliant Standards | IEEE 802.3, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s |
| Interfaces | 1 x 1000Base-T RJ-45 management ¦ 32 x SFP |
| Expansion Slots | 1 (total) / 1 (free) x expansion slot |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 0 (installed) / 2 (max) |
| Power Redundancy | Optional |
| Power Redundancy Scheme | 1 1 (with optional power supply) |
| Compliant Standards | BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, CISPR 22, EN50082-1, EN 61000-6-1, AS/NZS 60950-1, ICES-003 Class A, RoHS, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, GB 4943, CAN/CSA C22.2 No. 60950-1 |
| Width | 17.3 in |
| Depth | 30 in |
| Height | 1.7 in |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 158 °F |
| Humidity Range Storage | 5 - 95% (non-condensing) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
