| Manufacturer | Cisco |
| Product Line | Cisco Catalyst |
| Series | Catalyst 9115AX |
| Product Type | Wi-Fi 6 Indoor Access Point |
| Regulatory Domain | B (FCC / North America) |
| Wi-Fi Standard | 802.11ax (Wi-Fi 6), backward compatible 802.11a/b/g/n/ac |
| Frequency Bands | 2.4 GHz and 5 GHz (concurrent dual-band) |
| MIMO | 4x4:4 on both 2.4 GHz and 5 GHz |
| Spatial Streams | 4 (downlink MU-MIMO) |
| Max Throughput | 5.38 Gbps combined |
| OFDMA | Uplink and downlink |
| BSS Coloring | Yes |
| Target Wake Time (TWT) | Yes |
| Antennas | 4 x integrated internal dual-band omnidirectional — 3 dBi peak (2.4 GHz) / 4 dBi peak (5 GHz) |
| Bluetooth | BLE 5.0 (location services, asset tracking, wayfinding) |
| Wired Uplink | 1 x 100/1000/2500 Multigigabit RJ45 (IEEE 802.3bz) |
| USB | 1 x USB 2.0 |
| PoE Input | IEEE 802.3af / 802.3at PoE+, Cisco UPOE / UPOE+ |
| Max Power Draw | 20.4W (802.3at full feature) |
| Security | WPA3, WPA2, 802.1X, MACsec, Trustworthy Systems |
| Management | Cisco Catalyst Center, Cisco wireless controllers, Cisco Prime Infrastructure |
| DRAM | 2,048 MB |
| Flash | 1,024 MB |
| Dimensions | 8.00 x 8.00 x 1.50 in. |
| Weight | 1.98 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
