| Attribute | C6800-SUP6T | C6800-SUP6T-XL |
| MAC entries | 128K | 128K |
| Routes | 256K (IPv4) 128K (IPv6) | Up to 1024K (IPv4) Up to 512K (IPv6) |
| ACL entries | 64K shared for QoS and security | 256K shared for QoS and security |
| NetFlow entries | 512K per PFC4/4XL | 1024K per PFC4/4XL |
| Multicast routes | Up to 128K (IPv4) Up to 128K (IPv6) | Up to 128K (IPv4) Up to 128K (IPv6) |
| IPv4 routing | In hardware Up to 780 Mpps* | In hardware Up to 780 Mpps* |
| IPv6 routing | In hardware Up to 390 Mpps* | In hardware Up to 390 Mpps* |
| Layer 2 bridging | In hardware Up to 780 Mpps | In hardware Up to 780 Mpps |
| Jumbo frame support | Up to 9216 bytes (for bridged and routed packets) | Up to 9216 bytes (for bridged and routed packets) |
| VLAN | 4K | 4K |
| Bridge domains | 16K | 16K |
| MPLS | MPLS in hardware to support use of Layer 3 VPNs and Ethernet over (EoMPLS) tunneling Up to 8192 VRFs, with a total of up to 256K forwarding entries per system | MPLS in hardware to support use of Layer 3 VPNs and EoMPLS tunneling Up to 8192 VRFs, with a total of up to 1024K forwarding entries per system |
| Logical interfaces | 128K | 128K |
| EtherChannel hash | 8 bits | 8 bits |
| VPLS | In hardware (up to 390 Mpps) | In hardware (up to 390 Mpps) |
| Generic Routing Encapsulation (GRE) | In hardware (up to 390 Mpps) | In hardware (up to 390 Mpps) |
| Network Address Translation (NAT) | Hardware assisted | Hardware assisted |
| Onboard memory | 4 GB | 4 GB |
| Ingress buffers | 1.25 MB per 10-Gb port in 2:1 mode 2.5 MB per 10-Gb port in 1:1 mode (10 MB per port ASIC) | 1.25 MB per 10-Gb port in 2:1 mode 2.5 MB per 10-Gb port in 1:1 mode (10 MB per port ASIC) |
| Egress buffers | 250 MB per 10-Gb port in 2:1 mode 1 GB per 40-Gb port in 2:1 mode 500 MB per 10-Gb port in 1:1 mode 2 GB per 40-Gb port in 1:1 mode (2 GB per fabric interface and replication engine (FIRE) ASIC) | 250 MB per 10-Gb port in 2:1 mode 1 GB per 40-Gb port in 2:1 mode 500 MB per 10-Gb port in 1:1 mode 2 GB per 40-Gb port in 1:1 mode (2 GB per fabric interface and replication engine (FIRE) ASIC) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
