| Brand | Cisco |
| Model | PWR-IE480W-PCAC-L |
| Type | AC to DC Industrial Power Supply |
| Output Power | 480 W maximum |
| PoE Support | Yes (PoE, PoE+, 4PPoE) |
| Input Voltage | AC 100 to 240 V, 6 A, 50 to 60 Hz |
| Supported Input Range | AC 90 to 264 V |
| Output Voltage | 54 VDC nominal, adjustable 48 to 56 VDC |
| Output Current | 8.9 A |
| Typical Efficiency | 92% |
| Inrush Current (25 C) | Less than 35 A at 115 VAC and 230 VAC |
| Hold-Up Time (100% Load) | 20 ms |
| Input Connection | Hardwired |
| Mounting | DIN rail |
| Ingress Protection | IP20 |
| Hazardous Locations | Not approved |
| Operating Temperature | -40 C to 75 C |
| Power Derating (Vertical Mounting) | Above 50 C, 2.5% per C; above 70 C, 5% per C |
| Storage Temperature | -40 C to 85 C |
| Operating Humidity | 5% to 95% non-condensing |
| Dimensions (W x H x D) | 144 x 121 x 118.6 mm (5.66 x 4.76 x 4.66 in) |
| Weight | 3.02 lb (1.37 kg) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
