| Brand | Cisco |
| Model | N9K-C9396PX |
| Series | Cisco N9300 Platform Switches |
| Cisco Ordering Description | N9300 with 48p 1/10G SFP+ and 12p 40G QSFP |
| Ports | 48 x 1/10G SFP+ (fixed) |
| Supported Speeds | 1G and 10G Ethernet |
| Uplink Module Slot | 1 (an uplink module is required for normal switch operation) |
| Uplink Module Options | N9K-M6PQ and N9K-M6PQ-E (6 x 40G QSFP+), N9K-M12PQ (12 x 40G QSFP+), N9K-M4PC-CFP2 (4 x 100G CFP2) |
| N9K-M4PC-CFP2 Optics Support | CFP2 optics, and Cisco CPAK 100G modules through converters |
| Uplink Port Breakout | The 40G ports on the uplink module do not support 4 x 10G breakout |
| Throughput | 1.92 Tbps |
| Packet Forwarding Rate | Over 1500 Mpps |
| Latency (N9300 Platform) | 1 to 2 microseconds |
| Packet Buffer (N9300 Platform) | Up to 50 MB of integrated shared buffer |
| CPU (N9300 Platform) | Dual-core 2.5 GHz x86 |
| System Memory (N9300 Platform) | 16 GB |
| SSD (N9300 Platform) | 64 GB |
| Management Port | 1 x RJ-45 out-of-band |
| Serial Console | 1 x RS232 |
| USB Ports | 2 (USB 2.0 devices drawing under 0.5 A, including surge current) |
| Power Supplies | 2 hot-swap, 1+1 redundant |
| Power Supply Options | N9K-PAC-650W (650 W AC, port-side exhaust), N9K-PAC-650W-B (650 W AC, port-side intake), UCSC-PSU-930WDC (930 W DC, port-side intake), N9K-PUV-1200W (1200 W HVAC and HVDC) |
| Power Supply Efficiency (N9000 Series) | 80 Plus Platinum |
| AC Input | 100 to 240 V, 50 to 60 Hz |
| HVAC Input | 200 to 277 V |
| DC Input | -48 to -60 V |
| HVDC Input | -240 to -380 V |
| Fans | 3 hot-swap fan modules, 2+1 redundant |
| Fan Module Options | N9K-C9300-FAN2-B (port-side exhaust) and N9K-C9300-FAN2 (port-side intake) |
| Airflow | Port-side intake or port-side exhaust, set by the fan modules and power supplies installed; airflow direction must match across modules |
| Typical and Maximum Power Draw | 232 W / 455 W (AC) |
| Acoustics | 68.3 dBA at 40% fan speed, 78.8 dBA at 70% fan speed, 84.5 dB at 100% fan speed |
| Rack Units | 2 RU |
| Dimensions (H x W x D) | 3.5 x 17.5 x 22.5 in (8.9 x 44.5 x 57.1 cm) |
| Weight | 22.45 lb (10.2 kg), chassis without power supplies, fans or uplink module |
| Uplink Module Weight | N9K-M6PQ 2.0 lb (0.9 kg), N9K-M12PQ 3.12 lb (1.4 kg), N9K-M4PC-CFP2 2.6 lb (1.2 kg) |
| Power Supply Weight | 2.42 lb (1.1 kg) each for 650 W AC, 930 W DC and 1200 W HVAC and HVDC models |
| Fan Module Weight | N9K-C9300-FAN2 and N9K-C9300-FAN2-B 1.14 lb (0.5 kg) each |
| NX-OS Software Release (N9000 Series) | 6.1 and later |
| Operating Modes | Cisco NX-OS mode, with hardware ready for Cisco ACI mode |
| Fabric Extender Support | Connects 10G and 40G Cisco N2000 Series Fabric Extenders, up to 16 per switch |
| Layer 2 Scale (N9300 Platform) | 4096 VLANs, 96,000 MAC address entries, 507 RPVST instances, 64 MST instances, 528 PortChannels, 32 links per PortChannel (MAC address maximum depends on the system forwarding mode) |
| Layer 3 Scale (N9300 Platform) | 128,000 LPM routes, 208,000 IP host entries, 1000 VRF instances, 64 ECMP paths, 490 HSRP groups (route and host maximums depend on the system forwarding mode) |
| Multicast Scale (N9300 Platform) | 32,000 multicast routes, 32,000 IGMP snooping groups |
| ACL Scale (N9300 Platform) | 4000 ingress entries, 1000 egress entries |
| Overlay Scale (N9300 Platform) | 256 VXLAN tunnel endpoints |
| Monitoring (N9300 Platform) | 4 active SPAN sessions |
| Layer 2 Security and Management (N9000 Series) | Comprehensive Layer 2 security and management feature set |
| Layer 3 (N9300 Platform) | IP unicast and IP multicast routing, equal-cost multipath routing |
| Overlay (N9000 Series) | VXLAN bridging and routing at line rate |
| NX-OS Software (N9000 Series) | Modular operating system with a dedicated process for each routing protocol, hot and cold patching, online diagnostics |
| Provisioning and Programmability (N9000 Series) | Power-On Auto Provisioning (POAP), Intelligent API (iAPI) for managing the switch through remote procedure calls |
| Operating Temperature | 0 to 40 C (32 to 104 F) |
| Storage Temperature | -40 to 70 C (-40 to 158 F) |
| Relative Humidity | 5% to 95%, noncondensing |
| Operating Altitude | 0 to 4,000 m (0 to 13,123 ft) |
| Safety (N9300 Platform) | UL 60950-1 Second Edition, with CAN/CSA, EN, IEC, AS/NZS and GB4943 versions of 60950-1 |
| EMC Emissions (N9300 Platform) | 47CFR Part 15 (CFR 47) Class A, with AS/NZS CISPR22, CISPR22, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22 and CNS13438 Class A |
| EMC Immunity (N9300 Platform) | EN55024, CISPR24, EN300386 and the KN 61000-4 series |
| CE Marking (N9300 Platform) | Directives 2004/108/EC and 2006/95/EC |
| RoHS | RoHS-6 compliant, with exceptions for leaded ball grid array balls and lead press-fit connectors |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
