| Manufacturer | Cisco |
| Product Line | NCS 5500 Series |
| Product Type | Modular Line Card |
| Ports | 24x 100 Gigabit Ethernet |
| Transceiver Form Factor | QSFP28/QSFP+ |
| Scale Tier | High-Scale (SE) — Up To 8x FIB Capability vs. Base NC55-24X100G-SB Sibling |
| Forwarding ASICs | 4 |
| FIB Scale | Up To 2M IPv4 or 512K IPv6 Routes (Up To 2.75M IPv4 With Additional Memory) |
| On-Chip Tables | 750K IPv4 Host Routes, MAC, and Labels |
| On-Chip TCAM | Network ACLs and QoS |
| Power Consumption | 678W Typical / 940W Maximum |
| Dimensions (H x W x D) | 1.68 x 16.89 x 17.05 in |
| Weight | 15.3 lb (6.94 kg), Without Optics |
| MTBF | 157,570 Hours |
| Redundancy | Redundant Fan Tray, Redundant AC or DC Power Supply |
| Jumbo Frames | Up To 9,216 Bytes |
| ECMP | 32-Way |
| Power Input | Worldwide AC (90-265V, 50-60Hz) or DC (-40V to -72V) |
| Airflow | Front-to-Back |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Operating Altitude | 0 to 10,000 ft |
| Compatible Chassis | Any NCS 5500 Series Modular Chassis |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
