| Device Type | Expansion module |
|---|---|
| Form Factor | Plug-in module |
| Ports | 100 Gigabit QSFP28 x 32 |
| Connectivity Technology | Wired |
| Data Link Protocol | 100 Gigabit Ethernet |
| Performance | Bandwidth: 6.4 Tbps ¦ Bandwidth: 9.52 Bpps |
| Capacity | Longest prefix match (LPM) entries (IPv4): 600000 ¦ Longest prefix match (LPM) entries (IPv6): 300000 ¦ IP host entries: 600000 ¦ MAC address entries: 64000 ¦ Multicast routes: 32000 ¦ VLANs supported: 4096 ¦ Virtual Routing and Forwarding (VRF) instances: 1000 ¦ Per VLAN Rapid Spanning Tree instances: 507 ¦ MST instances: 64 |
| Features | Hot Standby Router Protocol (HSRP) support VXLAN tunnel endpoints (VTEP) support 160MB packet buffer |
| Interfaces | 32 x 100Gb Ethernet - QSFP28 |
| MTBF | 405240 hours |
| Compliant Standards | CISPR 22 Class A CISPR 24 EN 61000-3-2 EN 61000-3-3 EN55024 AS/NZS 60950-1 EMC ICES-003 Class A FCC CFR47 Part 15 UL 60950-1 Second Edition RoHS GB 4943 Directive 2004/108/EC EN 60950-1 Second Edition IEC 60950-1 Second Edition Directive 2006/95/EC VCCI Class A KN22 Class A EN 55022 Class A CNS 13438 Class A CAN/CSA C22.2 No. 60950-1 Second Edition EN 300 386 KN 61000-4 |
| Weight | 12.13 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
