| Device Type | Switch - L3 - managed - with Cisco Nexus 9500 Supervisor (N9K-SUP-A) 2x Cisco Nexus 9500 System Controller (N9K-SC-A) 6x Cisco Fabric Module (N9K-C9508-FM) |
| Enclosure Type | Rack-mountable 13U |
| Capacity | Virtual interfaces (VLANs): 4096 |
| Routing Protocol | Static IP routing |
| Remote Management Protocol | SNMP 1 SNMP 2 RMON SNMP 3 SSH-2 |
| Authentication Method | RADIUS TACACS |
| Features | Flow control modular design load balancing VLAN support auto-uplink (auto MDI/MDI-X) Weighted Round Robin (WRR) queuing Broadcast Storm Control Multicast Storm Control Unicast Storm Control Weighted Random Early Detection (WRED) Spanning Tree Protocol (STP) support Rapid Spanning Tree Protocol (RSTP) support Multiple Spanning Tree Protocol (MSTP) support Access Control List (ACL) support Quality of Service (QoS) RDMA support LLDP support Link Aggregation Control Protocol (LACP) Class of Service (CoS) DiffServ Code Point (DSCP) support |
| Compliant Standards | IEEE 802.3z IEEE 802.1D IEEE 802.1Q IEEE 802.3x IEEE 802.3ad (LACP) IEEE 802.1w IEEE 802.3ae IEEE 802.1s IEEE 801.1p IEEE 802.1ab (LLDP) IEEE 802.3ba |
| Expansion Slots | 18 (total) / 9 (free) x expansion slot |
| Installed Modules Qty (Max) | 9 (installed) / 18 (max) |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 3 (installed) / 3 (max) |
| Power Redundancy | Yes |
| Power Provided | 3000 Watt |
| Voltage Required | AC 230 V (50 - 60 Hz) |
| Features | Front-to-rear airflow |
| Included Accessories | Rack mount kit 3 fan trays |
| Compliant Standards | CISPR 22 Class A CISPR 24 EN 61000-3-2 EN 61000-3-3 EN55024 AS/NZS 60950-1 ICES-003 Class A RoHS UL 60950-1 Second Edition GB 4943 CSA C22.2 No. 60950-1 Second Edition EN 60950-1 Second Edition VCCI Class A KN22 CNS 13438(95) Class A EN 55022 Class A EN 300 386 |
| Width | 17.5 in |
| Depth | 31.8 in |
| Height | 22.7 in |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
