Cisco N3K-C3524P-10GX Nexus 3524x Switch 24 SFP - New

Roll over image to zoom in Click on image to zoom

Cisco N3K-C3524P-10GX

Upgrade your enterprise network’s performance using the Cisco Nexus 3524-X Switch. With Cisco Algorithm Boost technology, it achieves low Layer 2 and 3 latencies for increased productivity. Use its latency monitoring tools to gain real-time insights into specific egress ports. With support for Switched Port Analyzer (SPAN) and Encapsulated Remote SPAN (ERSPAN) technologies, this switch allows filter configuration. It uses IEEE 1588 Precision Time Protocol (PTP) and Pulse-Per-Second output (PPS) to deliver accurate time synchronization for applications. The Cisco Nexus 3524-X managed switch comes in a compact 1 rack unit (1 RU) mountable form factor that helps save server room space. It offers 24 enhanced small form-factor pluggable (SFP+) ports to support use in high-density applications.

Customer Support

We commit to providing excellence in customer service. We are available 24/7, highly responsive, transparent and offer product, transaction and logistics support.
Our philosophy is to be a part of the solution for our clients, so please contact us with any questions or concerns. Check our feedback rating to see what others thought about their experience with us. We look forward to offering you a Five Star member service.

For more information please visit our support page.

Product Code	N3K-C3524P-10GX
Physical	● 24 fixed SFP ports (1 or 10 Gbps); expandable to 48 ports ● Dual redundant hot-swappable power supplies ● Four individual redundant hot-swappable fans ● One 1-PPS timing port, with the RF1.0/2.3 QuickConnect connector type* ● One 10/100/1000-Mbps management port ● One RS-232 serial console port ● Two USB ports ● Locator LED ● Locator LED button
Performance	● 480-Gbps switching capacity ● Forwarding rate of 360 mpps ● Line-rate traffic throughput (both Layer 2 and 3) on all ports ● Configurable MTUs of up to 9216 bytes (jumbo frames)
Typical operating power	102W
Maximum power	193W
Typical heat dissipation	348 BTUs per hr
Maximum heat dissipation	658 BTUs per hr
Weight	17.4 lb (7.9 kg)
Dimension (H x W x D)	1.72 x 17.3 x 18.38 in. (4.36 x 43.9 x 46.7 cm)

We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
