| Manufacturer | Cisco |
| Product Line | Nexus 3000 |
| Series | Nexus 3064-T |
| Product Type | Layer 2/3 Data Center Switch |
| Access Ports | 48x 10GBase-T RJ45 (100M/1G/10G) |
| Uplink Ports | 4x QSFP+ (40G native or 4x10G breakout) |
| Management Ports | 2x 10/100/1000 Mbps RJ45 |
| Switching Capacity | 1.28 Tbps |
| Forwarding Rate | 950 Mpps |
| Jumbo Frames | Up to 9,216 bytes |
| MAC Address Table | 128,000 entries |
| VLANs | Up to 4,096 |
| Routing Table | 16,000 prefixes; 16,000 host entries; 8,000 multicast routes |
| ACL Entries | 2,000 ingress; 1,000 egress |
| EtherChannels | 64 (with vPC); up to 32 ports per EtherChannel |
| Buffer | 9 MB shared |
| Layer 2 | 802.1Q VLANs; MSTP; RSTP; vPC; LACP (802.3ad); storm control; private VLANs |
| Layer 3 Routing | OSPFv2; BGP; EIGRP; RIPv2; HSRP; VRRP; VRF-lite; 64-way ECMP; static routing |
| Multicast | PIM-SM; SSM; MSDP; IGMP v2/v3 |
| Security | ACLs (ingress/egress); DHCP snooping; Dynamic ARP Inspection; CoPP; VACL; PACL |
| QoS | 8 hardware queues/port; DSCP marking; WRED; ECN; 802.1p CoS |
| Management | NX-OS; POAP; Python scripting; SNMP v1/v2/v3; SSHv2; TACACS+; RADIUS; syslog; PTP (IEEE 1588) |
| Power Supplies | 2x hot-swappable AC; 100-240 VAC, 50-60 Hz |
| Cooling | Redundant fan tray; port-side exhaust or port-side intake airflow |
| Operating Temperature | 0 to 40°C (32 to 104°F) |
| Operating Humidity | 10% to 85% non-condensing |
| Operating System | Cisco NX-OS |
| Form Factor | 1U rack-mountable |
| Compliance | UL 60950-1; CE; FCC Class A; VCCI; RoHS |
| Dimensions | 1.72 x 17.3 x 22.45 in |
| Weight | 20.8 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
