| Brand | Cisco Meraki |
| Model | Z3-HW |
| Series | Z3 Series |
| Product Type | Cloud Managed Teleworker Gateway |
| WAN Interface | 1 x GbE RJ45 |
| LAN Interfaces | 4 x GbE |
| PoE | 1 x PoE enabled port (802.3af, 15.5 W) |
| USB | 1 x USB 2.0 port for 3G / 4G connectivity |
| Stateful Firewall Throughput | 100 Mbps |
| VPN Throughput | 50 Mbps |
| Recommended Clients | 5 clients or fewer |
| Wireless Standard | 802.11a/b/g/n/ac (Wi-Fi 5), 2.4 GHz or 5 GHz |
| Wireless Configuration | 2x2 MU-MIMO with 2 spatial streams |
| Maximum Wireless Data Rate | 1.3 Gbps |
| SSIDs | 4 |
| Antennas | 4 x internal dipole (3 dBi at 2.4 GHz, 4 dBi at 5 GHz) |
| Wi-Fi Security | WPA2-PSK |
| VPN | Auto VPN site-to-site, Client VPN (IPsec L2TP), limit 2 authorized users (Meraki-hosted authentication only) |
| Network Services | Stateful firewall, 1:1 NAT, DMZ, automatic Layer 3 failover, multiple WAN IP/PPPoE/NAT, VLAN support, static routing, 802.1X wired port authentication, user/device quarantine |
| Traffic Control | Application level traffic analysis and shaping |
| Monitoring | Throughput and connectivity monitoring, email alerts, per-port and per-client usage statistics, application usage statistics, change logs, VPN tunnel and latency monitoring, asset discovery, syslog integration |
| Remote Diagnostics | Live remote packet capture, real-time diagnostic tools, aggregated event logs with instant search |
| Management | Meraki cloud dashboard, zero-touch remote deployment, automatic firmware upgrades, centralized policy management, org-level two-factor authentication, role-based administration |
| Power Supply | 50 W (54 V / 0.92 A) universal power supply, power cord sold separately |
| Mounting | Desktop or wall mount, Kensington lock hard point |
| Dimensions (L x W x H) | 6.83 x 4.41 x 1.04 in (173.4 x 112 x 26.3 mm) |
| Weight | 0.85 lb (0.386 kg) |
| Operating Temperature | 32 to 104 F (0 to 40 C) |
| Humidity | 5 to 95% non-condensing |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
