| Manufacturer | Cisco |
| Product Line | Meraki MR |
| Series | MR86 |
| Product Type | Wireless Access Point |
| Wi-Fi Standard | 802.11ax (Wi-Fi 6) |
| IEEE Standards | 802.11a/b/e/g/h/i/k/n/ac/ax/r/u |
| MIMO | 4x4:4 SU-MIMO, UL/DL MU-MIMO, OFDMA |
| Radios | 4 (2.4 GHz, 5 GHz, WIDS/WIPS, BLE) |
| Aggregate Throughput | 3.0 Gbps (2,402 Mbps 5 GHz; 574 Mbps 2.4 GHz) |
| Channel Widths | 20, 40 MHz (2.4 GHz); 20, 40, 80 MHz (5 GHz) |
| Modulation | Up to 1024-QAM (2.4 GHz and 5 GHz) |
| Advanced Features | DL/UL-OFDMA, TWT, BSS Coloring, beamforming, MRC |
| Frequency Bands | 2.401-2.484 GHz; 5.150-5.350 GHz (UNII-1/2A); 5.490-5.730 GHz (UNII-2C); 5.735-5.825 GHz (UNII-3) |
| Bluetooth | BLE scanning and beaconing |
| Antenna | External connectors; MA-ANT-20/25/27, AIR-ANT2513P4M-N compatible (sold separately) |
| Uplink Port | 1x 100/1000/2.5GBase-T RJ45 |
| PoE | 802.3at; 42.5-57V; 30W max |
| Security | WPA/WPA2/WPA3-PSK and Enterprise; AES/TKIP; EAP-TLS/TTLS/MSCHAPv2/SIM; Layer 7 firewall; Air Marshal WIDS/WIPS |
| QoS | WMM, U-APSD, DSCP, 802.1p, Layer 7 shaping |
| Roaming | PMK, OKC, 802.11r |
| VLAN | 802.1q; IPsec VPN tunneling |
| IP Rating | IP67 |
| Operating Temperature | -40 to 55°C (-40 to 131°F) |
| Operating Humidity | 5% to 95% non-condensing |
| Operating Altitude | Up to 40,000 ft (12,192 m) |
| MTBF | 1,566,656 hours at 25°C |
| Physical Security | Security screws; anti-tamper cable bay |
| LED Indicators | 1x power/boot/firmware status |
| Mounting | Wall and vertical pole |
| Compliance | RoHS; UL 2043; FCC; ICES-003; CE; VCCI |
| Dimensions | 11.81 x 6.02 x 2.16 in (excluding cable gland, mounts, and antennas) |
| Weight | 3.31 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
