| Brand | Cisco |
| Model | CBS350-24NGP-4X |
| Series | Cisco Business 350 Series |
| Product Type | Managed Switch |
| Access Ports | 16 x 10/100/1000 PoE+ and 8 x 100M/1G/2.5G/5G PoE+ |
| Uplink Ports | 4 x 10G (2 x 10G copper/SFP+ combo and 2 x SFP+) |
| PoE Standards | 802.3af, 802.3at (PoE+), 60W PoE on 8 ports |
| PoE Budget | 375W across 24 ports |
| Switching Capacity | 192.0 Gbps |
| Forwarding Rate | 142.85 Mpps (64-byte packets) |
| Packet Buffer | 3 MB |
| MAC Address Table | 16K addresses |
| Active VLANs | Up to 4,094 |
| Jumbo Frames | Up to 9K bytes |
| Default MTU | 2K bytes |
| Stacking | Up to 4 units, up to 200 ports as a single system with hardware failover |
| IPv4 Static Routes | Up to 990 |
| IP Interfaces | Up to 128 |
| Flash Memory | 256 MB |
| DRAM | 512 MB |
| CPU | 800 MHz ARM |
| Power Supply | Internal universal, 100 to 240V, 50 to 60 Hz |
| Power Consumption | 56.9 W at 110V, 56.6 W at 220V (no PoE) |
| Power Consumption with PoE | 488.9 W at 110V, 474.5 W at 220V |
| Fans | 3 |
| Acoustic Noise | 40.4 dB at 25 C |
| Dimensions (W x D x H) | 17.3 x 13.78 x 1.73 in (44 x 35 x 4.4 cm) |
| Weight | 11.68 lb (5.3 kg) |
| Operating Temperature | 32 to 122 F (0 to 50 C) |
| Operating Humidity | 10% to 90%, relative, noncondensing |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
