| Manufacturer | Cisco Systems |
| Product Line | Catalyst 3560-CX Series |
| Part Number | WS-C3560CX-8PC-S |
| Product Type | Layer 3 Managed Compact Switch |
| Access Ports | 8x 10/100/1000BASE-T RJ-45 (PoE+) |
| PoE Standard | IEEE 802.3af; IEEE 802.3at (PoE+); 30W max per port |
| PoE Budget | 240W |
| Uplink Ports | 2x 1G SFP + 2x 1G copper RJ-45 (all usable simultaneously; also usable as downlinks) |
| Switching Capacity | 32 Gbps |
| Forwarding Rate | 17.9 Mpps |
| Software | Cisco IOS IP Base (upgradeable to IP Services via RTU license) |
| Layer 3 | OSPF; EIGRP; BGP; static routing; RIP; IPv4/IPv6; PBR (IP Services) |
| Security | MACsec; Cisco TrustSec; 802.1X; ACLs; DHCP snooping; Dynamic ARP inspection; Port security |
| Management | Cisco IOS CLI; web UI; SNMP; Bluetooth over-the-air; Cisco Network Plug-and-Play; 1x RJ-45 console; 1x USB mini-B console |
| Cooling | Fanless (silent operation) |
| Mounting | Desktop; wall; under-desk; DIN rail |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
