| Manufacturer | Cisco |
| Product Line | Catalyst 9600 Series |
| Product Type | Modular Switch Chassis |
| Total Slots | 6 (4 Line Card + 2 Dedicated Supervisor Engine, Slots 3 and 4) |
| Supervisor Redundancy | 1+1, SSO, NSF, ISSU |
| Supported Supervisors | C9600-SUP-1 (Cisco UADP 3.0), C9600X-SUP-2 (Cisco S1 Q200) |
| Wired Switching Capacity (Hardware-Ready) | 25.6 Tbps (12.8 Tbps Full-Duplex) |
| Per-Slot Bandwidth (Hardware-Ready) | Up To 6.4 Tbps (3.2 Tbps Full-Duplex) |
| Per-Slot Bandwidth (With C9600-SUP-1) | 2.4 Tbps |
| Port Scale (SFP56) | Up To 224 Native 10/25/50G (Up To 256 With Breakout) |
| Port Scale (QSFP28) | Up To 128 Native 40/100G |
| Port Scale (QSFP-DD) | Up To 8 Native 400G |
| Fan Tray | 1x Field-Replaceable (C9600-FAN), 9 Independently Controlled Fans |
| Airflow | Side-to-Side |
| Power Supply Bays | 4 |
| Operating Temperature | 23 to 113°F, Up To 6,000 ft / 23 to 104°F, Up To 10,000 ft |
| Storage Temperature | -40 to 167°F |
| Form Factor | 8U Rack Mountable |
| Dimensions | 13.95 x 17.4 x 16.1 in |
| Chassis Weight (No Fan Tray, No PSU) | 55.90 lb (25.36 kg) |
| Fan Tray Weight | 7.85 lb (3.56 kg) |
| PSU Weight | 3000W AC: 3.09 lb / 2000W AC: 2.65 lb / 2000W DC: 2.82 lb |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
