| Brand | Cisco |
| Model | C9500-48Y4C-A |
| Series | Cisco Catalyst 9500 Series Switches |
| Cisco Product Description | Cisco Catalyst 9500 Series high-performance 48-port 1/10/25 Gigabit Ethernet switch with SFP28 |
| Product Type | Fixed high-performance Ethernet switch |
| Software Tier | Network Advantage (-A suffix) |
| Downlink Ports | 48 x 1/10/25G SFP28 |
| Uplink Ports | 4 x 40/100G QSFP28 |
| Port Density, 1G, 10G and 25G | 48 each |
| Port Density, 40G and 100G | 4 each |
| Network Module Support | None (fixed ports) |
| ASIC | Cisco UADP 3.0 |
| Switching Capacity | Up to 3.2 Tbps |
| Forwarding Rate | Up to 1 Bpps |
| DRAM | 16 GB |
| Flash | 16 GB |
| Optional SSD Modules | C9K-F1-SSD-240G, C9K-F1-SSD-480G, C9K-F1-SSD-960G |
| Scale Note | Maximums vary with the selected flexible ASIC template |
| MAC Addresses | Up to 82,000 |
| IPv4 Routes (Indirect and Direct) | Up to 256,000 |
| IPv4 Host Routes (Direct and ARP) | Up to 90,000 |
| IPv6 Routes (Indirect and Direct) | Up to 256,000 |
| IPv6 Host Routes (Direct and NDP) | Up to 90,000 |
| IPv4 Multicast Routes | Up to 32,000 |
| IPv6 Multicast Routes | Up to 32,000 |
| QoS ACL Scale (IPv4/IPv6) | Up to 16,000/8,000 |
| Security ACL Scale (IPv4/IPv6) | Up to 27,000/13,500 |
| Flexible NetFlow Entries | Up to 256,000 |
| VLAN IDs | 4,094 |
| PVST Instances | 4,000 |
| STP Virtual Ports (PVST) | 16,000 |
| Switched Virtual Interfaces | 4,000 |
| Jumbo Frames | 9,216 bytes |
| Power Supply Slots | 2 |
| Power Supply Options | C9K-PWR-650WAC-R and C9K-PWR-650WACL-R (650 W AC), C9K-PWR-930WDC-R (930 W DC) |
| AC Input | 90 to 264 VAC, 47 to 63 Hz |
| DC Input | -40 to -72 VDC |
| Power Supply Efficiency | 94% typical (AC), 92% typical (DC) |
| Total Output Heat | 1,856 BTU per hour |
| Fan Tray | C9K-T1-FANTRAY (up to 4 fans) |
| Dimensions (H x W x D) | 1.73 x 17.5 x 18.0 in (4.4 x 44.5 x 45.7 cm) |
| Weight, Chassis with 2 Power Supplies | 21.96 lb (9.96 kg) |
| MTBF | 316,960 hours |
| Operating Temperature | 32 to 104 F (0 to 40 C) |
| Storage Temperature | -4 to 149 F (-20 to 65 C) |
| Relative Humidity, Operating | 5% to 90%, noncondensing |
| Relative Humidity, Nonoperating and Storage | 5% to 95%, noncondensing |
| Storage Altitude | Up to 15,000 ft (4,500 m) |
| Minimum Software Release | Cisco IOS XE 16.8.1a |
| Related Models | C9500-24Y4C (24 x 1/10/25G SFP28, 4 x 40/100G QSFP28) |
| Other Tier Variant | C9500-48Y4C-E (same configuration, Network Essentials) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
