| Manufacturer | Cisco Systems |
| Product Line | Catalyst 9500 Series |
| Part Number | C9500-40X-E |
| Product Type | Layer 2/3 Core/Aggregation Switch |
| ASIC | Cisco UADP 2.0 |
| Fixed Ports | 40x 1/10G SFP+ |
| Module Slot | 1x (C9500-NM-8X or C9500-NM-2Q; module not included) |
| PoE | None |
| Switching Capacity | 960 Gbps |
| Forwarding Rate | 720 Mpps |
| MAC Address Table | 64,000 entries |
| IPv4 Routes | Up to 64,000 indirect; up to 32,000 host |
| IPv6 Routes | Up to 32,000 indirect; up to 16,000 host |
| VLANs | 4,000 |
| SVIs | 4,000 |
| FNF Entries | Up to 512,000 |
| CPU | Intel 2.4 GHz x86 |
| DRAM | 16 GB |
| Flash | 16 GB |
| Stacking | StackWise Virtual (2-switch active/standby logical unit) |
| Layer 2 | VLAN; 802.1Q; MSTP; RSTP; LACP; VTP; SPAN/RSPAN; MACsec AES-256 |
| Layer 3 | OSPF; EIGRP; BGP; RIP; PBR; VRF-Lite; MPLS; PIM-SM/SSM; static IPv4/IPv6 |
| Security | MACsec AES-256; TrustSec; 802.1X; ACLs; DHCP snooping; ARP inspection; CoPP |
| QoS | Yes; hardware-based; up to 18,000 QoS ACL entries |
| License | Network Essentials |
| Management | Web UI; CLI; SNMP; RJ45 console; USB console; 1x GE out-of-band management |
| Power Supply | 950W AC (1 included; 2nd slot for 1+1 redundancy; hot-swappable) |
| Cooling | Front-to-back airflow; 5x hot-swappable fans |
| Form Factor | 1U rack-mountable |
| Dimensions | 1.73 x 17.5 x 21.52 in |
| Weight | 25.75 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
