| Manufacturer | Cisco |
| Product Line | Catalyst 9500 Series |
| Product Type | Core and Aggregation Switch |
| QSFP+ Ports | 12x 40 Gigabit Ethernet |
| SFP+ Ports | 12x |
| License | Network Advantage, Adds BGP, EIGRP, StackWise Virtual, MACsec-256 (Sibling C9500-12Q-E is Network Essentials, Same Hardware) |
| ASIC | UADP 2.0 |
| Switching Capacity | 480 Gbps |
| Forwarding Rate | 720 Mpps |
| DRAM / Flash | 16GB / 16GB |
| VLAN IDs | 4,000 |
| Flexible NetFlow Entries | Up To 512,000 |
| Jumbo Frames | 9,198 Bytes |
| Power Supplies | Dual, 950W AC Max Rating, Platinum-Rated |
| System Power Consumption | Up To 850W |
| Power Supply Efficiency | 94% |
| Input Voltage | 115 to 230VAC, 50 to 60Hz |
| Heat Output | 2,901 BTU/hr (850W) Max |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Storage Temperature | -4 to 149°F (-20 to 65°C) |
| Humidity | 5 to 90% Non-Condensing |
| Dimensions (H x W x D) | 1.73 x 17.5 x 21.52 in |
| Weight | 25.75 lb (11.68 kg), With 2 Power Supplies |
| Form Factor | 1U Rack Mountable |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
