| Manufacturer | Cisco |
| Model / Part Number | C9400-SUP-1XL |
| Product Family | Catalyst 9400 Series |
| Device Type | Supervisor Engine 1XL |
| Switching Capacity | Up to 3.2 Tbps |
| Per-Slot Bandwidth | Up to 480 Gbps |
| ASIC / Processor | Cisco UADP 2.0 XL / x86 CPU |
| System Memory | 16 GB DRAM |
| Uplink Interfaces | 2 x 40G QSFP+ or 8 x 10G SFP+ |
| Advanced Security | Hardware-based MACsec 256-bit |
| Supported Chassis | Cisco Catalyst 9404R, 9407R, 9410R |
| Software Compatibility | Cisco IOS XE |
| Redundancy | 1+1 Stateful Switchover (SSO) |
| Form Factor | Plug-in module |
| VLANs Supported | 4094 |
| MAC Address Table | 128,000 entries |
| Routing Protocols | OSPF, BGP, IS-IS, EIGRP, VRF-Lite |
| Operating Temperature | 23°F to 113°F |
| Dimensions (H x W x D) | 1.6 x 14.9 x 14.5 in |
| Weight | Approx. 10.0 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
