| Manufacturer | Cisco |
| Product Line | Cisco Catalyst |
| Series | Catalyst 9300LM |
| Product Type | Stackable Managed Switch |
| Ports | 24 x 10/100/1000 UPOE RJ45 + 4 x 25G SFP28 fixed uplinks |
| PoE Standard | Cisco UPOE, IEEE 802.3af / 802.3at, up to 60W per port |
| PoE Budget | 420W (default 600W PSU) / 1,440W (optional 1kW PSU) |
| PoE Features | Perpetual PoE, Fast PoE, StackPower |
| Switching Capacity | 248 Gbps (568 Gbps with stacking) |
| Forwarding Rate | 184.51 Mpps (422.59 Mpps with stacking) |
| Packet Buffer | 16 MB |
| ASIC | Cisco UADP 2.0 |
| MAC Address Table | 32,000 entries |
| VLANs | 4,094 |
| SVIs | 1,000 |
| IPv4 Routes | 32,000 |
| IPv6 Routes | 16,000 |
| Multicast Scale | 8,000 |
| ACL Scale | 5,120 entries |
| QoS Scale | 5,120 entries |
| FNF Entries | 64,000 flows |
| Stacking | StackWise-320, up to 8 C9300LM switches, 320 Gbps; C9300LM-STACK-KIT required (sold separately) |
| Layer 3 | OSPFv2/v3, EIGRP, BGP, VRF-Lite, MPLS, VXLAN EVPN, PIM-SM/SSM |
| Security | MACsec 256-bit, TrustSec SGT, 802.1X, DHCP snooping, IP Source Guard, CoPP, Trustworthy Systems |
| License | Network Advantage |
| DRAM | 8 GB |
| Flash | 16 GB |
| Operating System | Cisco IOS XE |
| Power Supply | 1x 600W AC included (1kW AC optional), 2 slots, second PSU optional |
| Fans | 3 (field-replaceable, N+1 redundancy) |
| Form Factor | 1U rack-mountable |
| Dimensions | 1.73 x 17.50 x 13.17 in. |
| Weight | 11.50 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
