| Model | C9300L-24UXG-2Q-E |
| Series | Cisco Catalyst 9300L Series |
| Port Configuration | 24 x UPOE (8 Multigigabit 100M/1G/2.5G/5G/10G, 16 x 1G/100M), 2 x 40G QSFP+ Fixed Uplinks |
| Switching Capacity | 352 Gbps (Standalone), 672 Gbps (Stacked) |
| Forwarding Rate | 261.90 Mpps (Standalone), 500.00 Mpps (Stacked) |
| Stacking | StackWise-320, 320 Gbps |
| PoE Budget | 722W (Default 1100W Supply), Up to 1,440W (1900W Secondary Supply) |
| Default Power Supply | PWR-C1-1100WAC-P |
| Routing Protocols | Static Routing, OSPF, EIGRP, BGPv4, IS-ISv4, OSPFv3, BGPv6 |
| Dimensions (H x W x D) | 1.73 x 17.5 x 19.2 in. (4.4 x 44.5 x 48.8 cm) |
| Weight | 16.01 lb (7.26 kg) |
| Operating Temperature | -5°C to 45°C (23°F to 113°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Operating Humidity | 5% to 90% Noncondensing |
| Operating Altitude | Up to 10,000 ft (3,000 m) |
| Storage Altitude | Up to 15,000 ft (4,500 m) |
| Local Storage | USB 2.0 Slot for System Image Loading |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
