| Brand | Cisco |
| Model | C9200-48T-E |
| Series | Cisco Catalyst 9200 Series Switches |
| Cisco Product Description | Catalyst 9200 48-port Data switch modular uplinks, Network Essentials |
| Product Type | Stackable Gigabit Ethernet data switch with modular uplinks |
| Software Tier | Network Essentials (-E suffix) |
| Downlink Ports | 48 x Gigabit Ethernet, data only (no PoE) |
| Uplinks | Modular, through a network module |
| Compatible Network Modules | C9200-NM-4X (4 x 1G/10G), C9200-NM-BLANK |
| Switching Capacity | 176 Gbps |
| Switching Capacity with Stacking | 336 Gbps |
| Forwarding Rate | 130.95 Mpps |
| Forwarding Rate with Stacking | 250 Mpps |
| Stacking | StackWise-160, 160 Gbps, up to 8 members |
| Stack Kit | C9200-STACK-KIT (two stack adapters and one stack cable) |
| Stack Cable Lengths | 50 cm, 1 m, 3 m |
| Stackable With | Other Catalyst 9200 models at the same tier; Catalyst 9200L is not supported |
| Power Supply Slots | 2 |
| Primary Power Supply | PWR-C6-125WAC (125 W AC, 100 to 240 VAC, 50 to 60 Hz) |
| Second Power Supply | A second identical power supply can be added with the order or later |
| Fans | Dual fans, FRU redundant |
| DRAM | 4 GB |
| Flash | 4 GB |
| Security | Image signing, secure boot, Cisco Trust Anchor module |
| Resiliency | Cross-stack EtherChannel, MSTP, PVRST+, err-disable auto-recovery |
| MAC Addresses | 32,000 |
| IPv4 Routes | 14,000 (10,000 direct, 4,000 indirect) |
| IPv6 Routing Entries | 2,000 |
| ACL Scale Entries | 1,600 |
| QoS Scale Entries | 1,000 |
| VLAN IDs | 4,094 |
| PVST Instances | 128 |
| STP Virtual Ports (PVST and MST) | 13,000 |
| Switched Virtual Interfaces | 512 |
| Jumbo Frames | 9,198 bytes |
| Packet Buffer | 6 MB |
| Flexible NetFlow Entries | 16,000 flows |
| Management Port | 1 x RJ-45 Ethernet |
| Console Port | RJ-45 or mini USB |
| Dimensions (H x W x D) | 1.73 x 17.5 x 13.8 in (4.4 x 44.5 x 35.0 cm) |
| Weight | 11.02 lb (5.0 kg) |
| MTBF | 571,440 hours |
| Related Models | C9200-48P-E (48 PoE+ ports, modular uplinks), C9200-24T-E (24 data ports, modular uplinks) |
| Other Tier Variant | C9200-48T-A (same configuration, Network Advantage) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
