| Ports | 6 x 10/100/1000 RJ45 (WAN/LAN) |
| Management Ports | 1 x RJ45 console + 1 x USB console + 1 x 10/100/1000 mgmt |
| Module Slots | 1 x SM, 1 x NIM, 1 x PIM |
| Processor | 8-core Intel x86 |
| DRAM | 8 GB default (upgradeable to 32 GB) |
| Flash | 8 GB on-board (non-upgradeable) |
| M.2 Storage | 16 GB default (upgradeable to 600 GB or 2 TB NVMe) |
| SD-WAN IPsec Throughput (1400B) | Up to 2 Gbps |
| SD-WAN IPsec Throughput (IMIX) | 1.8 Gbps |
| CEF Throughput | Up to 10 Gbps |
| SD-WAN Overlay Tunnels | Up to 6,000 |
| Security | NGFW, IPS/IDS, MACsec, IPsec hardware acceleration, SSL/TLS offload |
| Routing | BGP, OSPF, IS-IS, EIGRP, RIP, MPLS, VRF, VRRP, BFD |
| WAN | SD-WAN (Cisco Catalyst SD-WAN / IOS XE), DMVPN, FlexVPN |
| Power Supply | Dual hot-swappable — AC 250W/500W or DC 400W (1+1 redundancy) |
| Operating System | Cisco IOS XE |
| Form Factor | 1U rack-mountable |
| Dimensions | 1.70 x 17.50 x 16.30 in. |
| Weight | ~20.00 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
