| Model | Cisco C1200-16P-2G |
| Series | Cisco Catalyst 1200 Series |
| Switch Type | Smart switch, PoE+ |
| Downlink Ports | 16 x 10/100/1000 Gigabit Ethernet RJ-45 PoE+ |
| Uplink Ports | 2 x Gigabit SFP (not combo ports) |
| Console | Cisco standard RJ-45 console and USB Type C |
| PoE Standards | 802.3at PoE+, 802.3af PoE, Cisco prestandard PoE |
| PoE Ports | 16 |
| Maximum Power per Port | 30W |
| Total PoE Budget | 120W |
| Switching Capacity | 36 Gbps, wire-speed and nonblocking |
| Forwarding Rate | 26.78 Mpps (64-byte packets) |
| Packet Buffer | 1.5 MB, shared dynamically across all ports |
| Power Input | 100-240V AC, 50-60 Hz, internal universal supply |
| Power Consumption (System) | 17.4W at 110V, 17.2W at 220V |
| Power Consumption (With PoE) | 143.9W at 110V, 141.4W at 220V |
| Idle Power | 10.4W at 110V, 10.2W at 220V |
| Heat Dissipation | 490.7 BTU/hr |
| Cooling | Fanless |
| Dimensions (W x D x H) | 268 x 297 x 44 mm (10.56 x 11.69 x 1.73 in) |
| Weight | 2.38 kg (5.25 lb) |
| Rack Mounting | Rack-mountable |
| Operating Temperature | -5C to 50C (23F to 122F) |
| Storage Temperature | -25C to 70C (-13F to 158F) |
| Operating and Storage Humidity | 10% to 90% relative, noncondensing |
| Spanning Tree | 802.1d, RSTP, MSTP (8 instances), PVST+ and RPVST+ (126 instances each) |
| Link Aggregation | LACP, up to 4 groups with up to 8 ports each |
| VLANs | Up to 255 active VLANs |
| IGMP Snooping | IGMP v1, v2 and v3, 255 groups |
| IPv4 Static Routing | 32 routes, 16 IP interfaces |
| Jumbo Frames | 9,000 bytes |
| MAC Address Table | 8,000 entries |
| ACL | Up to 512 rules |
| QoS | 8 hardware queues |
| Port Mirroring | 4 sources |
| Discovery | Bonjour, LLDP and CDP |
| Energy Efficiency | IEEE 802.3az EEE |
| Security | 802.1X, RADIUS, port security, storm control |
| Management | SNMP v1/v2c/v3, RMON, SSH, SSL |
| Cisco Business Dashboard | Embedded probe |
| Firmware | Dual firmware images |
| Cabling | Cat 5e or better for 1000BASE-T |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
