| Brand | Cisco |
| Model | ASR1000-SIP10 |
| Series | ASR 1000 Series |
| Type | SPA Interface Processor (SIP) Carrier Card |
| Bandwidth | Up to 10 Gbps of oversubscription |
| SPA Bays | 4 half-height SPAs or 2 full-height SPAs (quarter rate, full rate or a combination) |
| Ports per Half-Height SPA | Up to 16 |
| Ports per Full-Height SPA | Up to 32 |
| Mixed Configuration | 2 half-height SPAs and 1 full-height SPA, up to 64 ports in total |
| SPA Families | Copper, channelized, POS, ATM and Ethernet |
| Compatible Chassis | Cisco ASR 1004, Cisco ASR 1006 |
| Integrated Version, ASR 1002 | ASR1002-SIP10: built in to the chassis, not field-replaceable; built-in 4xGE SPA plus three removable half-height SPAs in bays 1, 2 and 3 |
| Integrated Version, ASR 1002-F | ASR1002-SIP10-F: three removable half-height SPAs in bays 1, 2 and 3 |
| Online Insertion and Removal | Supported for the SIP with SPAs installed; SPAs can be inserted or removed independently |
| Subslot Filler (sold separately) | SPA-BLANK= |
| Higher-Bandwidth Model | ASR1000-SIP40: up to 40 Gbps aggregate bandwidth; up to 24 ports per half-height SPA, 48 per full-height SPA, 96 combined |
| PWR LED | Solid green: SIP powered on and all power supplies within tolerance; off: SIP powered off |
| STATUS LED | Red: error; yellow: SIP loading; solid green: SPA drivers started and all critical processes running |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
