| Description | Specification |
| Chassis compatibility | Compatible with the Cisco ASR 9006, ASR 9010, ASR 9904, ASR 9906, ASR 9912 and ASR 9922 chassis |
| Port density | 4-ports and 8 ports of 100 Gigabit Ethernet per line card |
| Performance | 100-Gbps line-rate throughput per port |
| Options | Each line card is available as either a service edge optimized (enhanced QoS) or packet transport optimized (basic QoS) line card |
| Reliability and availability | Line card Online Insertion and Removal (OIR) support without system impact |
| Physical dimensions (H x W x D); weight | 8-port 100 Gigabit Ethernet Line Card: 14.5 x 1.63 x 22.02 in.; 28 lb (est.) (368.3 mm x 41.4 mm x 559.3 mm; 12.7 kg) 4-port 100 Gigabit Ethernet Line Card: 14.5 x 1.63 x |
| Physical dimensions (H x W x D); weight (cont.) | 22.02 in.; 28 lb (est.) (368.3 mm x 41.4 mm x 559.3 mm; 12.7 kg) |
| Operating temperature | 41 to 104°F (5 to 40°C) |
| Operating humidity (nominal) (relative humidity) | 10 to 85% |
| Storage temperature | –40 to 158°F (–40 to 70°C) |
| Storage (relative humidity) | 5 to 95% Note: Not to exceed 0.024 kg of water per kg of dry air |
| Operating altitude | –60 to 4000m (up to 2000m conforms to IEC, EN, UL, and CSA 60950 requirements) |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
