| Manufacturer | Cisco |
| Model | A99-RP2-SE |
| Series | ASR 9900 |
| Module Type | Route Processor 2 (Service Edge Optimized) |
| Processor | 8-core, 1.9 GHz |
| Memory | 32 GB ECC-protected DRAM |
| Storage | 2 x 32 GB SSD, 8 GB embedded USB |
| Redundancy | 1+1 RP redundancy (NSF/NSR, no single point of failure) |
| Fabric Control | Up to 7 ASR 9900 switch fabric cards (multistage, nonblocking, low-latency) |
| Operating System | Cisco IOS XR (minimum 5.3.0) |
| Chassis Compatibility | ASR 9912, 9922 |
| Timing | SyncE, IEEE 1588v2 PTP (dedicated 10/100 Mbps RJ-45), 2 x independent BITS clock sources |
| GPS | ToD (RS-422 / RS-232), 1PPS (RS-422 or 1.0/2.3 50-ohm RF), 10 MHz in/out (1.0/2.3 50-ohm RF) |
| Management Interfaces | 2 x 100/1000BASE-T RJ-45 LAN Management, Console port, Auxiliary port, USB 2.0 Type-A |
| Alarms | Critical (CR), Major (MJ), Minor (MN) alarm outputs |
| LEDs | ACO / Lamp Test, SYNC, GPS, Fabric-card fault, SSD activity |
| Routing Protocols | BGP, OSPF, OSPFv3, IS-IS, EIGRP, RIP, Static Routing, Segment Routing |
| MPLS | LDP, RSVP-TE, MPLS TE-FRR, P2MP-TE, Segment Routing |
| VPN Services | L2VPN, L3VPN, EVPN, VPLS, MC-LAG, IRB, mVPN |
| QoS | Hierarchical QoS (H-QoS), virtual output queuing, centralized arbitration |
| High Availability | NSF/NSR, SMU hitless patching, FPD upgrades, zero-packet-loss switchover |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Humidity | 10% to 90% (non-condensing) |
| Dimensions (H x W x D) | 1.81 x 16.87 x 24.74 in |
| Weight | 17.8 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
