| Manufacturer | Cisco |
| Model | A99-RP-F |
| Series | ASR 9900 |
| Module Type | Fixed Chassis Route Processor |
| Processor | 64-bit Intel CPU |
| Memory | 16 GB DDR4 |
| Routing Capacity | Up to 1.6 Tbps |
| Redundancy | 1+1 RP redundancy (NSF/SSO) |
| Operating System | Cisco IOS XR (64-bit) |
| Chassis Compatibility | ASR 9901, 9903, 9906 |
| Routing Protocols | BGP, OSPF, OSPFv3, IS-IS, EIGRP, RIP, Static Routing, Segment Routing |
| MPLS | LDP, RSVP-TE, Segment Routing, MPLS-TP |
| VPN Services | L2VPN, L3VPN, EVPN, VPLS, mVPN |
| Multicast | PIM-SM, PIM-SSM, IGMP, MLD |
| Timing | SyncE, IEEE 1588v2, GPS (10 MHz, 1PPS, ToD), 2x BITS interfaces |
| Management Interfaces | 2 x Management Ethernet, Console port, Auxiliary serial port, USB Type-A |
| Security | MACsec, TrustSec, CoPP, uRPF, ACLs |
| Licensing | Traditional Business Model |
| Online Insertion and Removal | Yes |
| Dimensions (H x W x D) | 1.5 x 16.9 x 24.4 in |
| Weight | 14.3 lbs |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
