| Brand | APC |
| Model | SYPM4KP |
| Product Line | Symmetra LX |
| Range | APC Symmetra Power Module |
| Product Type | UPS power module |
| Rated Power | 4000 VA, 3200 W |
| UPS Topology | Double-conversion on-line |
| Voltage Variant | 200/208 V |
| Output Voltage Range | 100 V to 208 V |
| Selectable Output Voltages | 100 V, 120 V, 200 V, 208 V |
| Input Frequency Range | 45 to 65 Hz |
| Output Frequency, Synchronized to Mains | 47 to 63 Hz |
| Output Frequency, Not Synchronized | 50 Hz or 60 Hz, within 0.1% |
| Output Waveform | Sine wave |
| Output Voltage Distortion | Under 5% at full load |
| Crest Factor | Up to 5:1 |
| Output Connection | Hardwired, 4-wire |
| Redundancy | N+1 configurable at rated load |
| Hot-Swap Capability | Hot-swappable |
| Modules per Frame for N+1 | Up to 3 in an 8 kVA frame; up to 5 in a 16 kVA frame |
| Battery Charge Power | 300 W per power module |
| Compatible System | Symmetra LX 208 V/240 V UPS frames |
| Related Models | SYPM4KI (220/230/240V, 4000 VA, 2800 W) |
| Audible Noise | 62 dBA at 1 meter |
| Operating Temperature | 32 to 104 F (0 to 40 C) |
| Storage Temperature | 5 to 113 F (-15 to 45 C) |
| Operating Relative Humidity | 0 to 95%, noncondensing |
| Operating Altitude | 0 to 3000 m |
| Safety and EMC | UL 1778, FCC Part 15 Class A, CSA certified |
Overview
- We perform an intensive quality control process on all our products. Units (unless sealed in the original manufacturer’s packaging) are fully tested and certified by our technicians. We run and record diagnostics on serial and operating systems, ensuring they function to the industry standard.
- Unless the listing specifies otherwise, this product comes with a 1 Year Warranty for the original purchaser as enduser of the equipment, applicable to items sold in the United States only. All others sales are supported by a 90 day extended warranty.
